#1
50 Hz 380-415 V 3N~
#2
60 Hz 380 V 3N~
Rated (kW)
22.4
Rated (kW)
22.4
Max (kW)
25.2
Max (Btu/h)
86000
Rated (kW)
6.10
Rated (kW)
5.16
EER(Rated) (W/W)
3.67
COP(Rated) (W/W)
4.34
SEER (Wh/Wh)
8.28
SCOP (Wh/Wh)
4.45
Pdesign(@-10℃, Heating) (kW)
13.7
Type
Propeller fan
Discharge direction(Side / Top)
Top
Air Flow Rate(High) (m³/min x No.)
220 x 1
Drive
Direct
Output (W x No.)
1,200 x 1
Type (kg)
Hermetically Sealed Scroll
Motor Output (W x No.)
5,300 × 1
Starting Method
Inverter
Oil Type
FW68L(PVE)
Piston Displacement (cm³/rev)
62.1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
930 x 1745 x 760
Shipping(W x H x D) (mm)
965 x 1919 x 802
Net (kg)
215
Shipping (kg)
225
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
Type
R410A
Precharged Amount (kg)
8.5
GWP(Global Warming Potential)
2,087.5
t-CO₂ eq.
17.744
Control Type
EEV
Liquid (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ19.05 (3/4)
Low Pressure Gas (Heat Recovery) (mm(inch))
Φ19.05 (3/4)
High Pressure Gas (Heat Recovery) (mm(inch))
Φ15.88 (5/8)
Max. (Conditional) (EA)
13(20)
Cooling / Heating (dB(A))
57 / 58
Cooling / Heating (dB(A))
78 / 78
Communication Cable(VCTF-SB) (mm² × cores)
0.75 ~ 1.5 x 2C
