Chassis
UXA
Combination Unit (1)
ZRUM080LTE6
Case 1 (V, Phase, Hz)
380-400-415, 3, 50
Limit Range of Voltage(Case 1) (V)
342 ~ 456
Case 2 (V, Phase, Hz)
380, 3, 60
Limit Range of Voltage(Case 2) (V)
342 ~ 418
Running Current by Voltage (Cooling,Rated) (A)
9.97 - 9.47 - 9.13
Running Current by Voltage (Heating,Rated) (A)
8.43 - 8.01 - 7.72
Rated (kW)
22.4
Rated (Btu/h)
76400
Rated (kW)
22.4
Rated (Btu/h)
76400
Max (kW)
25.2
Max (Btu/h)
86000
Rated (kW)
6.1
Rated (kW)
5.16
EER(Rated) (W/W)
3.67
COP(Rated) (W/W)
4.34
SEER (Wh/Wh)
8.28
SCOP (Wh/Wh)
4.45
Rated
0.93 / 0.93
Type
Propeller fan
Air Flow Rate(High) (m³/min x No.)
220
Max. External Static Pressure (Pa)
80
Discharge direction(Side / Top)
Top
Type
BLDC
Drive
Direct
Output (W x No.)
1,200 x 1
Type (kg)
Hermetically Sealed Scroll
Piston Displacement (cm³/rev)
62.1
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
5,300 × 1
Starting Method
Inverter
Oil Type
FW68L(PVE)
Type
Fin & Tube
No.
1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
930 x 1,745 x 760
Shipping(W x H x D) (mm)
965 x 1,919 x 802
Net (kg)
215
Shipping (kg)
225
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
High Pressure Prevention
High pressure sensor / High pressure switch
Frost Prevention
O (Logical)
Discharge Temperature Control
O (Logical)
Compressor/Fan Protection
Over-heat protection / Fan driver overload protector
Inverter Protection
Over-heat protection / Over-current protection
Type
R32
Precharged Amount (kg)
7.5
GWP(Global Warming Potential)
675
t-CO₂ eq.
5.063
Control Type
EEV
Liquid (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ19.05 (3/4)
Low Pressure Gas (Heat Recovery) (mm(inch))
Φ19.05 (3/4)
High Pressure Gas (Heat Recovery) (mm(inch))
Φ15.88 (5/8)
Liquid
Brazing
Gas
Brazing
Low Pressure Gas (Heat Recovery)
Brazing
High Pressure Gas (Heat Recovery)
Brazing
Cooling / Heating (dB(A))
57.0 / 58.0
Measurement Standard (Pressure Level)
ISO 3745
Cooling / Heating (dB(A))
78.0 / 78.0
Measurement Standard (Power Level)
ISO 9614
Communication Cable(VCTF-SB) (mm² × cores)
1.0 x 2C
Minimium Circuit Amperes (MCA) (A)
18.2
Maximum Fuse Amperes (MFA) (A)
20
Total Over Current Amperes (TOCA) (A)
20
Comp_Maximum Starting Current (MSC) (A)
5.9
Comp_Rated Load Amperes (Cooling) (A)
7.5
Comp_Rated Load Amperes (Heating) (A)
5.9
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
2.5
Max. (Conditional) (EA)
13(20)
