Heat Pump-Heat Recovery Unit, Outdoor Unit, MULTI V, 16HP, R32
Key Features
LG MULTI V i offers powerful and reliable performance even in extreme weather, providing fresh and comfortable indoor air year-round, with full cooling capacity up to 43°C outdoor temperature and full heating capacity up to -10°C outdoor temperature.
The AI engine in LG MULTI V i enables AI Smart Care, helping to enhance efficiency and reduce energy consumption. It utilizes data from each indoor unit to provide the optimized operation depending on indoor environment.
AI Smart Metering monitors the energy used and saved by MULTI V i using operational data collected by the AI Engine via Smart Plug logic, displaying the results on the controller screen for monitoring energy footprint.
Chassis
UXB
Combination Unit (1)
ZRUM160LTE6
Case 1 (V, Phase, Hz)
380-400-415, 3, 50
Limit Range of Voltage(Case 1) (V)
342 ~ 456
Case 2 (V, Phase, Hz)
380, 3, 60
Limit Range of Voltage(Case 2) (V)
342 ~ 418
Running Current by Voltage (Cooling,Rated) (A)
25.24 - 23.98 - 23.11
Running Current by Voltage (Heating,Rated) (A)
16.48 - 15.65 - 15.09
Rated (kW)
44.8
Rated (Btu/h)
152900
Rated (kW)
44.8
Rated (Btu/h)
152900
Max (kW)
50.4
Max (Btu/h)
172000
Rated (kW)
15.45
Rated (kW)
10.09
EER(Rated) (W/W)
2.9
COP(Rated) (W/W)
4.44
SEER (Wh/Wh)
7.97
SCOP (Wh/Wh)
5.46
Rated
0.93 / 0.93
Type
Propeller fan
Air Flow Rate(High) (m³/min x No.)
320
Max. External Static Pressure (Pa)
80
Discharge direction(Side / Top)
Top
Type
BLDC
Drive
Direct
Output (W x No.)
900 x 2
Type (kg)
Hermetically Sealed Scroll
Piston Displacement (cm³/rev)
62.1
Number of Revolution (rev./min)
3600
Motor Output (W x No.)
5,300 x 1
Starting Method
Inverter
Oil Type
FW68L(PVE)
Type
Fin & Tube
No.
1
Fin Type
Wide Louver Plus
Net(W x H x D) (mm)
1,240 x 1,745 x 760
Shipping(W x H x D) (mm)
1,282 x 1,919 x 802
Net (kg)
255
Shipping (kg)
265
Color
Morning Gray / Dawn Gray
RAL (Classic)
RAL 7038 / RAL 7037
High Pressure Prevention
High pressure sensor / High pressure switch
Frost Prevention
O (Logical)
Discharge Temperature Control
O (Logical)
Compressor/Fan Protection
Over-heat protection / Fan driver overload protector
Inverter Protection
Over-heat protection / Over-current protection
Type
R32
Precharged Amount (kg)
11.4
GWP(Global Warming Potential)
675
t-CO₂ eq.
7.695
Control Type
EEV
Liquid (mm(inch))
Φ12.7 (1/2)
Gas (mm(inch))
Φ22.2 (7/8)
Low Pressure Gas (Heat Recovery) (mm(inch))
Φ22.2 (7/8)
High Pressure Gas (Heat Recovery) (mm(inch))
Φ19.05 (3/4)
Liquid
Brazing
Gas
Brazing
Low Pressure Gas (Heat Recovery)
Brazing
High Pressure Gas (Heat Recovery)
Brazing
Cooling / Heating (dB(A))
60.5 / 61.5
Measurement Standard (Pressure Level)
ISO 3745
Cooling / Heating (dB(A))
85.0 / 85.0
Measurement Standard (Power Level)
ISO 9614
Communication Cable(VCTF-SB) (mm² × cores)
1.0 x 2C
Minimium Circuit Amperes (MCA) (A)
27.3
Maximum Fuse Amperes (MFA) (A)
32
Total Over Current Amperes (TOCA) (A)
30
Comp_Maximum Starting Current (MSC) (A)
5.9
Comp_Rated Load Amperes (Cooling) (A)
22.7
Comp_Rated Load Amperes (Heating) (A)
14
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
2.5
Max. (Conditional) (EA)
26(40)
