All Spec
POWER SUPPLY
-
#1
-
50 Hz(Гц) 380-415 V(B) 3N~
COOLING CAPACITY
-
Rated (kW)
-
12.1
HEATING CAPACITY
-
Rated (kW)
-
12.5
COMPRESSOR
-
Type (kg)
-
BLDC Inverter Twin Rotary
-
Motor Output (W x No.)
-
4000 x 1
-
Starting Method
-
Inverter
-
Oil Type
-
FW68D(PVE)
-
Piston Displacement (cm³/rev)
-
44.2
POWER INPUT(COOLING)
-
Rated (kW)
-
3.39
POWER INPUT(HEATING)
-
Rated (kW)
-
2.75
EFFICIENCY
-
EER(Rated) (W/W)
-
3.57
-
COP(Rated) (W/W)
-
4.55
-
SEER (Wh/Wh)
-
7.42
-
SCOP (Wh/Wh)
-
4.30
-
Pdesign(@-10℃, Heating) (kW)
-
8.0
OUTDOOR FAN
-
Type
-
Axial Flow fan
-
Discharge direction(Side / Top)
-
Side
-
Air Flow Rate(High) (m³/min x No.)
-
110
OUTDOOR FAN MOTOR
-
Drive
-
DC Inverter
-
Output (W x No.)
-
124x2
HEAT EXCHANGER
-
Fin Type
-
Wide Louver Plus
DIMENSION
-
Net(W x H x D) (mm)
-
950 x 1380 x 330
-
Shipping(W x H x D) (mm)
-
1140 x 1549 x 466
WEIGHT
-
Net (kg)
-
96
-
Shipping (kg)
-
108
EXTERIOR
-
Color
-
Warm Gray
-
RAL (Classic)
-
RAL 7044
REFRIGERANT
-
Type
-
R410A
-
Precharged Amount (kg)
-
3.0
-
GWP(Global Warming Potential)
-
2087.5
-
t-CO₂ eq.
-
6.263
-
Control Type
-
Electronic Expansion Valve
CONNECTING PIPE
-
Liquid (mm(inch))
-
Φ9.52 (3/8)
-
Gas (mm(inch))
-
Φ15.88 (5/8)
SOUND PRESSURE LEVEL (OUTDOOR UNIT)
-
Cooling / Heating (dB(A))
-
50/52
SOUND POWER LEVEL (OUTDOOR UNIT)
-
Cooling / Heating (dB(A))
-
72/76
CONNECTABLE INDOOR UNITS NUMBER
-
Max. (Conditional) (EA)
-
8
CONNECTING CABLE
-
Communication Cable(VCTF-SB) (mm² × cores)
-
1.0~1.5x2
COMPLIANCE INFORMATION
