All Spec
POWER SUPPLY
-
#1
-
50 Hz 380-415 V 3N~
-
#2
-
380, 3, 60
COOLING CAPACITY
-
Rated (kW)
-
39.2
HEATING CAPACITY
-
Rated (kW)
-
44.1
POWER INPUT(COOLING)
-
Rated (kW)
-
6.22
COMPRESSOR
-
Type (kg)
-
Hermetically Sealed Scroll
-
Model x No.
-
JQC068MAA x 1
-
Number of Revolution (rev./min)
-
3600
-
Oil Charging amount (cc x No.)
-
1,200 x 1
-
Motor Output (W x No.)
-
5300 x 1
-
Starting Method
-
Direct On Line
-
Oil Type
-
FW68D(PVE)
-
Piston Displacement (cm³/rev)
-
62.1
POWER INPUT(HEATING)
-
Rated (kW)
-
6.78
RATED WATER FLOW ( LPM )
-
Rated Water Flow ( LPM )
-
135
HEAD LOSS ( KPA )
-
Head loss ( kPa )
-
29.6
HEAT EXCHANGER
-
Type
-
Stainless Steel Plate
-
Maximum Pressure Resistance (kg/cm²)
-
45
DIMENSION
-
Net(W x H x D) (mm)
-
772 x 1120 x 547
WATER CONNECTING PIPES
-
Inlet (mm)
-
PT 40 (Internal Thread)
-
Outlet (mm)
-
PT 40 (Internal Thread)
WEIGHT
-
Net (kg)
-
149 x 1
EXTERIOR
-
Color
-
Morning Gray / Dawn Gray
-
RAL (Classic)
-
RAL 7038 / RAL 7037
REFRIGERANT
-
Type
-
R410A
-
Precharged Amount (kg)
-
3.5
-
Control Type
-
Electronic expansion valve
CONTINUOUS OPERATION RANGE (INDOOR TEMP.)
-
Cooling (°C(WB))
-
15 ~ 40
-
Heating (°C(DB))
-
15 ~ 40
OPERATIVE RANGE (INDOOR TEMP.)
-
Cooling (°C(WB))
-
10 ~ 45
-
Heating (°C(DB))
-
-5 ~ 45
CONNECTING PIPE
-
Liquid (mm(inch))
-
Φ12.7 (1/2)
-
Gas (mm(inch))
-
Φ28.58 (1-1/8)
-
Low Pressure Gas (Heat Recovery) (mm(inch))
-
Φ28.58 (1-1/8)
-
High Pressure Gas (Heat Recovery) (mm(inch))
-
Φ22.22 (7/8)
SOUND PRESSURE LEVEL (OUTDOOR UNIT)
-
Cooling / Heating (dB(A))
-
52 / 53
SOUND POWER LEVEL (OUTDOOR UNIT)
-
Cooling / Heating (dB(A))
-
64 / 65
CONNECTING CABLE
-
Communication Cable(VCTF-SB) (mm² × cores)
-
1.0 ~ 1.5 × 2C
COMPLIANCE INFORMATION
