The user has easy access to air volume selection via the remote control by using the ESP control function. The BLDC motor can control the fan speed and air volume.
No additional accessories are needed to control air flow.
Get access to the unit anytime, anywhere with Android & iOS smartphones.
Depending on the installation environment, LG’s ceiling conceals duct controls of static pressure with 11 steps to provide maximised comfort to any environment.
Safe Plus Insulation is an antimicrobial treatment that is applied to the LG MULTI V Indoor unit. Internal insulation components create resistance against bacterial growth and provide cleaner and fresher airflow for the user.
#1
50 Hz 220-240 V~
#2
60 Hz 220 V~
Nominal (kW)
22.4
Nominal (kW)
25.2
Net(W x H x D) (mm)
1562 x 460 x 688
Net (kg)
87
Liquid (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ19.05 (3/4)
O.D / I.D (mm(inch))
25(1)
Air Flow Rate(Cooling,(SH)/H/M/L) (m³/min)
- / 60 / 50 / 50
External Static Pressure(Factory Set) (Pa)
216
Type
Concealed Duct
Cooling((SH)/H/M/L) (dB(A))
- / 67 / 62 / 60
Heating((SH)/H/M/L) (dB(A))
- / 67 / 62 / 60
Cooling((SH)/H/M/L) (dB(A))
- / 45 / 41 / 40
Heating((SH)/H/M/L) (dB(A))
- / 45 / 41 / 40
