A man explains content on the screen of an LAEC installed with a dedicated stand in an auditorium.
* All images in this page are for illustrative purposes only and may differ from the actual product.
* Stand accessories differ by models, and need to be purchased separately.
* The webOS Signage Developer site (https://webossignage.developer.lge.com) provides SDK tools and documentation for creating apps on LG Digital Signage. This is only open to partners.
The installation process of the All-in-One Smart series is very simple. After securing cabinets (two for LAEC015, three for LAEC018), attach each LED display module to them. Lastly, plug in the power cable. This simple installation saves time and labor, thereby making users handle the LED screen with ease.
This consists of total 3 steps' images for securing cabinets, attaching LED modules, and connecting the power cable.
* Fixing screws or installing wall mount / accessories is needed additionally.
* The image is illustrated as an example of LAEC015 model.
The product is offered with the necessary component including the landscape wall mount and tools for installation. The dedicated stand* is provided as an option, so that you can easily place it depending on your installation sites. Also, the LAEC series can be installed side by side in the form of 1 × N or 2 × N, up to 14 screens, suitable for its installation site and its purposes.
"The LAEC installed on the wall with wall mounted. The LAEC’s have been installed along with the optional dedicated stand in an event hall. Two LAECs are installed on a hotel's ballroom walls side by side"
* Stand accessories differ by models, and need to be purchased separately.
* The availability of LG ConnectedCare differs by region.
** Stand accessories differ by models, and need to be purchased separately.
* Initial setting from display is required for Crestron Connected® compatibility.
** Network based control
*** Crestron Connected® needs to be purchased separately.
* LG One:Quick Share needs to be purchased separately.
** Users need to set up SoftAP enabled at Network Menu of the Signage.
With the LG Magic Remote, you can select and run the menu of the signage just like using a mouse and its cursor can be used as a laser pointer. In addition, through the newly added 'FREEZE' button on the remote control, users can temporarily freeze the screen while switching contents on the PC, so that users are able to have uninterrupted meetings without exposing its switching process.
The functions of the LG Magic Remote are shown in two images. The left image show the Magic Remote’s function which allow it to be used as a laser pointer on the LAEC screen. The right image is the Freeze Function, and when the Freeze button on the Magic Remote is pressed, the LAEC screen installed on the conference room wall is paused.
* LG Magic Remote needs to be purchased separately.
** The FREEZE function is only available when the LAEC is connected to an external input signal.
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.88
Screen Resolution (WxH)
1,920 x 1,080
Module Dimensions(WxH,mm)
300 × 168.75
No. of Modules per Screen (WxH)
12 × 12 (Total 144)
Screen Dimensions (W x H x D, mm, including bezel)
3,604 × 2,029 × 45.5 (Thickest 81)
Screen Surface Area (㎡)
7.29
Cabinet material
Aluminum
Physical Pixel Density (pixels/㎡)
284,444
Flatness of Cabinet (mm)
±0.2
Service access
Front
Max. Brightness (After Calibration)
500
Color Temperature (K)
3,200 - 9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
98%
Color Uniformity
±0.015 Cx, Cy
Contrast Ratio
3,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Power Consumption (W/Screen, Max.)
2,200
Power Consumption (W/Screen, Avg.)
880
Power Consumption (W/㎡, Max.)
302
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,000
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0 to +40
Operating Humidity
10-90% RH
IP rating Front
IP30
IP rating Rear
IP20
Speaker
Built-in (9 W + 9 W)
Certification
CE, FCC, ETL, CB
Environment
RoHS, REACH
Controller
Embedded
