All Spec
PHYSICAL PARAMETERS
-
Pixel Configuration
-
Single SMD
-
Pixel Pitch (mm)
-
1.88
-
Screen Resolution (WxH)
-
1,920 x 1,080
-
Module Dimensions(WxH,mm)
-
300 × 168.75
-
No. of Modules per Screen (WxH)
-
12 × 12 (Total 144)
-
Screen Dimensions (W x H x D, mm, including bezel)
-
3,604 × 2,029 × 45.5 (Thickest 81)
-
Screen Surface Area (㎡)
-
7.29
-
Cabinet material
-
Aluminum
-
Physical Pixel Density (pixels/㎡)
-
284,444
-
Flatness of Cabinet (mm)
-
±0.2
-
Service access
-
Front
OPTICAL SPECIFICATIONS
-
Max. Brightness (After Calibration)
-
500
-
Color Temperature (K)
-
3,200 - 9,300
-
Visual Viewing Angle (Horizontal)
-
160
-
Visual Viewing Angle (Vertical)
-
160
-
Brightness Uniformity(%)
-
98%
-
Color Uniformity
-
±0.015 Cx, Cy
-
Contrast Ratio
-
3,000:1
-
Processing Depth (bit)
-
16 (HDR10, HDR10 Pro)
ELECTRICAL SPECIFICATIONS
-
Power Consumption (W/Screen, Max.)
-
2,200
-
Power Consumption (W/Screen, Avg.)
-
880
-
Power Consumption (W/㎡, Max.)
-
302
-
Power Supply (V)
-
100 to 240
-
Frame Rate (Hz)
-
50 / 60
-
Refresh Rate (Hz)
-
3,000
OPERATION SPECIFICATIONS
-
LED Lifetime (Half brightness)
-
100,000
-
Operating Temperature(℃)
-
0 to +40
-
Operating Humidity
-
10-90% RH
-
IP rating Front
-
IP30
-
IP rating Rear
-
IP20
SPEAKER
-
Speaker
-
Built-in (9 W + 9 W)
STANDARD
-
Certification
-
CE, FCC, ETL, CB
ENVIRONMENT
-
Environment
-
RoHS, REACH
CONTROLLER
-
Controller
-
Embedded
COMPLIANCE INFORMATION
