Model name
LSCB012-RKL
Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.25
Module Resolution (WxH)
240x135
Module Dimensions(WxH,mm)
300x168.75
Weight per Module (kg)
0.37
No. of Modules per Cabinet (WxH)
2x2
Cabinet Resolution (WxH)
480x270
Cabinet Dimensions (W x H x D, mm)
600x337.5x34
Cabinet Surface Area (㎡)
0.2
Weight per Cabinet (kg/unit)
5.3
Weight per Square Meter (kg/㎡)
26.17
Physical Pixel Density (pixels/㎡)
640,000
Flatness of Cabinet (mm)
±0.1
Cabinet material
Die-casting Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity(%)
97%
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Processing Depth (bit)
14 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
150
Power Consumption (W/Cabinet, Avg.)
50
Power Consumption (W/㎡, Max.)
740
Heat Dissipation (BTU/h/Cabinet, Max.)
512
Heat Dissipation (BTU/h/Cabinet, Avg.)
171
Heat Dissipation (BTU/h/㎡, Max.)
2,528
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-10℃ to +45℃
Operating Humidity
0~80%RH
IP rating Front
IP30
IP rating Rear
IP30
Certification
CE, FCC, ETL, EMC Class-B
Environment
RoHS, REACH
Controller
CVCA
90 degree corner cut
Yes
