All Spec
DISPLAY
-
Aspect Ratio
-
16:9
-
Backlight Dimming Technology
-
Global Dimming
-
Backlight Technology
-
LED
-
Backlight Type
-
Edge
-
Brightness (Min.)
-
650cd/m²
-
Brightness (Typ.)
-
800cd/m²
-
Brightness (Stabilization)
-
500cd/m²
-
Colour Bit
-
10bit
-
Colour Depth (Number of Colours)
-
1.07B
-
Colour Gamut (Typ.)
-
sRGB 115% (Area),
sRGB over 99% (Coverage)
-
Contrast Ratio (Typ.)
-
1300:1
-
Contrast Ratio with DFC
-
Mega
-
Panel Type
-
IPS
-
Peak Brightness (Min.)
-
650cd/m² (Peak)
-
Peak Brightness (Typ.)
-
800cd/m² (Peak)
-
Pixel Pitch (H x V)
-
0.18159mm x 0.18159mm
-
Resolution
-
3840 x 2160
-
Response Time (GTG)
-
14ms (Off-setting), 5ms (Faster-setting)
-
Size (Inch)
-
31.5
-
Size (cm)
-
80.0051
-
Surface Treatment
-
Protection Glass (1.6t, Anti-Reflection, Anti-fingerprint)
-
Viewing Angle (CR≥10)
-
178°(Right/Left), 178°(Up/Down)
FEATURE
-
Hot Key
-
Yes (2keys)
-
Brightness stabilization
-
Yes
-
Black Stabilizer
-
Yes
-
Factory Calibration
-
Yes (Delta E<5, Gamma 1.8~2.6/DICOM curve)
-
HW Calibration
-
Yes (True Color Pro)
-
DICOM Compliant
-
Yes
-
Colour Temperature
-
6500K/7500K/9300K
Manual (5000K ~ 10000K)
-
Flicker safe
-
Yes
-
HDR 10
-
Yes
-
HDR Effect
-
Yes
-
OSD Language
-
17 Language
-
PBP
-
Yes (2PBP/3PBP/4PBP)
-
PIP
-
Yes
-
Picture Mode
-
(SDR) Custom, Mono, Vivid, HDR Effect, DICOM, Calibration 1, Calibration 2, (HDR) Custom, Vivid, Standard
-
Rotation & Mirror Mode
-
Yes
-
Failover Input Switch
-
Yes
-
Smart Energy Saving
-
Yes
-
User Preset
-
Yes
-
Super Resolution+
-
Yes
-
Uniformity
-
Yes
SW APPLICATION
-
True Colour Pro
-
Yes
CONNECTIVITY
-
3G-SDI
-
Yes (12G INx1/OUTx1,Single, 2SI, Square, SFP)
-
12G-SDI
-
Yes (12G INx1/OUTx1,Single, 2SI, Square, SFP)
-
DisplayPort
-
Yes (in 1ea/out 1ea)
-
DP (HDCP Version)
-
2.2
-
DP (Max. Resolution at Hz)
-
3840 x 2160 at 60Hz
-
DP (H-Frequency)
-
30~135kHz
-
DP (V Frequency)
-
56~61Hz
-
DP Version
-
1.2
-
DVI
-
Yes (1In / 1Out)
-
DVI (Max Resolution at Hz)
-
1920 x 1080 at 60Hz
-
DVI (H Frequency)
-
30~83kHz
-
DVI (V Frequency)
-
56~61Hz
-
HDMI
-
Yes (1ea)
-
HDMI (HDCP Version)
-
2.2
-
HDMI (Max. Resolution at Hz)
-
3840 x 2160 at 60Hz
-
HDMI (H Frequency)
-
30~135kHz
-
HDMI (V Frequency)
-
56~61Hz
-
HDMI Version
-
2.0
-
RS-232
-
Yes (1ea)
-
USB Downstream Port
-
Yes (1ea/ver2.0)
-
USB Upstream Port
-
Yes (1ea/ver2.0)
-
[Location]
-
Bottom
POWER
-
AC Input
-
100-240Vac, 50/60Hz
-
DC Output
-
24V, 7.5A
-
Power Consumption (DC Off)
-
Less than 0.3W
-
Power Consumption (Max.)
-
180W
-
Type
-
External Power (Adapter)
MECHANICAL
-
Borderless Design
-
Normal
-
Colour (Back Cover)
-
White
-
Colour (Middle Cabinet)
-
Silver
-
Display Position Adjustments
-
No Stand
-
Down Height
-
No Stand
-
Height Range
-
No Stand
-
Machanical Power Switch
-
Yes
-
OneClick Stand
-
No Stand
-
Pivot
-
No Stand
-
Swivel
-
No Stand
-
Tilt
-
No Stand
-
Wall Mount Size
-
200 x 100mm/100 x 100mm
DIMENSIONS/WEIGHT
-
Dimension in Shiping (W x H x D)
-
883 x 599 x 200 mm
-
Dimension with Stand (W x H x D)
-
No Stand
-
Dimension without Stand (W x H x D)
-
764.6 x 480.8 x 94.4 mm
-
Pallet Stuffing (20ft/40ft/40ft HC)
-
216EA/405EA/495EA
-
Weight in Shipping
-
18.5kg (40.8lb)
-
Weight with Stand
-
No Stand
-
Weight without Stand
-
13.5kg (29.8lb)
STANDARD
-
IEC (IEC 60601-1 / IEC 60601-1-2)
-
Yes
-
EN (EN 60601-1 / EN 60601-1-2)
-
Yes
-
IEC (IEC 60950-1 / IEC 55032, 55024)
-
Yes
-
EN (EN 60950-1 / EN 55032, 55024)
-
Yes
-
cUL (ANSI/AAMI ES 60601-1, CSA CAN/CSA-C22.2 NO. 60601-1)
-
Yes
-
FCC (FCC part 15 Class A)
-
Yes
-
FDA
-
Registration (Class I)
-
ISO13485
-
Yes
-
GMP
-
Yes
-
KGMP
-
Yes
-
RoHS
-
Yes
-
REACH
-
Yes
-
WEEE
-
Yes
-
MFDS
-
Yes
-
IP (Front/Except for front)
-
IP35/IP32
-
Vandal-proof
-
IK06
ACCESSORY
-
Adapter
-
Yes
-
Adapter (Colour)
-
White
-
Calibration Report (Paper)
-
Yes
-
Display Port
-
Yes
-
Display Port (Colour/Length)
-
Black/1.8m
-
HDMI
-
Yes
-
HDMI (Colour/Length)
-
Black/1.8m
-
Power Cord
-
Yes
-
Power Cord (Colour/Length)
-
White/1.5m
WARRANTY
-
time/years
-
5 years (subject to terms and conditions)
