Native Resolution - Native Resolution
Full HD (1920x1080)
Brightness (ANSI Lumen) - Brightness (ANSI Lumen)
1000
Light Source - Type
4Ch(RGBB) LED
Contrast Ratio - Contrast Ratio
150,000:1
Features - Digital Keystone Correction
Edge Adjustment (HV 4 Corner Keystone)
Sound - Output
3W+3W Stereo
Features - Airplay 2 (iOS/Mac Video Casting, Mirroring, Audio Streaming)
○ (up to 4K/30Hz)
Features - Screen Share (Wireless Mirroring with MiraCast supporting device)
○
Projection Lens - Zoom
Fixed
Projection System
DLP
Native Resolution
Full HD (1920x1080)
Brightness (ANSI Lumen)
1000
Contrast Ratio
150,000:1
Energy Saving Min. (Bright)
29dB(A)
Energy Saving Med.
26dB(A)
Energy Saving Max. (Eco)
24dB(A)
Energy Saving Off (Max)
-
Uniformity (JBMMA 9 Point)
85%↑
Changeable F#
-
Focus (Auto / Manual)
Manual
Zoom
Fixed
Screen Size
60" ~ 120"
Standard (lens to wall)
60"@1.59m (100"@2.65m)
Throw Ratio
1.195
Lens Shift
-
Projection Offset
1
Type
4Ch(RGBB) LED
Life Hours
30,000 Hrs
OSD Languages
English(UK) / French/ Spanish/ German / Portuguese / Dutch / Russian / Polish/ Hungarian / Romanian / Slovenian / Croatian / Bulgarianv / Serbian / Italian / Czech /Turkish/Slovak / Norsk / Dansk / Suomi
Aspect Ratio Control
16:9/Original/4:3/Vertical Zoom/4-Way Zoom
Output
3W+3W Stereo
Clear Voice
○ (Clear Voice lll)
Dolby Surround Audio
-
Dolby Atmos compatible
○ (Pass Through)
WiSA Ready (Dongle)
-
DTS-HD
-
TI Audio Max
-
Running time
-
Capacity
-
Net Size (mm) (W x D x H)
225 x 192 x 69
Gross size (mm) (W x D x H)
-
Net Weight (kg or g)
1.65kg
Gross Weight (kg or g)
-
Power Consumption (Max.)
98W
Stand-by Power
<0.5W
Power Supply
Adapter 110W (100V – 240V @ 50~60 Hz)
Operation Temperature
0 ~ 40℃
RF
-
USB Type-C
-
Digital(HDMI)
Up to 1080p(60Hz, 50Hz, 24Hz)
RGB
-
Component Video
-
Composite Video
-
RGB in
-
RGB(PC) Audio in
-
RGB out
-
Composite(AV) in
-
Composite(AV) Audio in
-
S video
-
Component (YPbPr)
-
Component (YPbPr) Audio in
-
Audio out
1 (Φ3.5), S/PDIF 1(Optical)
RS-232C
-
IP control
-
RJ45
1
HDMI
2
HDBaseT
-
USB Type-A
2 (USB2.0)
USB Type-C (Display, Charging)
-
RF IN
-
CI Slot
-
12V Trigger
-
Platform (OS, UI)
webOS 5.0 (Smart)
Home Dashboard (Input, IoT with OFC device)
○ (OCF/UEI IoT not supported)
Background Image
○
Premium CP
○
Contents Store / LG Smart World (App Store)
○
Contents Suggestion
○
Internet Browser
○
DTV Tuner
-
Voice Recognition - Buit-in
-
AI Speaker Compatibility
Apple Homekit works-with
Screen Share (Wireless Mirroring with MiraCast supporting device)
○
Airplay 2 (iOS/Mac Video Casting, Mirroring, Audio Streaming)
○ (up to 4K/30Hz)
Wireless Contents Share (with Android, iOS)
-
Contents Sharing (with DLNA supporting device)
○
Bluetooth Sound out
○
Bluetooth AV Sync Control
○
LG Sound Sync(with Sound Bar)
○
HDMI ARC(Audio Return Channel)
○ (ARC)
HDMI simplink(CEC)
○
HDCP
HDCP2.2
Plug & Play(RGB/DVI/HDMI Auto Source Detection)
○
USB Host (Movie, Music, Photo)
○
File(Office) Viewer
-
Setting Guide
○ (Bean Bird)
HID (Keyboard/Mouse/GamePad Connection Thru USB)
○
Eco Function - Energy Saving Mode
○ (Min/Med/Max)
Eco Function - Sleep Timer
○
Eco Function - Auto Off / Auto Sleep
○
Eco Function - Time Power On/Off
○ (On / Off)
Eco Function - Automatic Standby / Auto Power Off
○
Eco Function - HDD Eco Mode
○
Processor
Quad Core
HDR
HDR10
HDR Effect
○
HDR Tone Mapping
○ (Dynamic, frame by frame)
DICOM
-
Brightness Optimizer - Iris Mode
-
Brightness Optimizer - Adaptive Contrast
-
TruMotion
-
Real Cinema
-
Upscaler
○ (Full HD)
Super Resolution (Expert Control)
○ (Full HD)
FILMMAKER mode
-
HGiG (HDR Gamming Interest Group) mode
-
Digital Keystone Correction
Edge Adjustment (HV 4 Corner Keystone)
Auto Keystone
○(Vertical)
Image Flip
○ (Horizontal/Vertical)
Callibration II (Auto Calibration / CalMan)
-
Smooth Gradation
○
Black Level Control
○
Noise Reduction
○
Color Temperature Adjustment
○
Dynamic Contrast (Expert control)
○
Dynamic Color (Expert control)
○
Dynamic Black
-
Color Management System (Expert control)
○
Color gamut setting (Expert control)
○
Gamma Correction (Expert control)
○
White balance setting (Expert control)
○
Brilliant Color™ (Overlap Duty)
-
Intelli Bright™ (CAIC / LABB)
-
Quick(Instant) Power on/off
○ (on 10 Sec off 2 Sec)
Store Mode
○
Built-in Memory (for Storage)
-
Blank
-
Picture Still
-
Closed Caption
-
Self Diagnosis
○
Edge Blending
-
Expert controlvADJ
-
Cabinet Color
Top - White / Bottom - Gray
Local Key
Joystick
Kensington Lock
○
Leg-Stand
○
Ceiling mount hole (for bracket)
-
Tripod hole (for Tripod, Ceiling mount)
○
Manual (Full or Simple Book)
Simple Book
Quick User Guide (Quick Set-up Guide)
-
Warranty Card
○
Remote Control - Motion
-
Remote Control - Normal
○
Conformances(Regulation)
CE/CB
