Native Resolution - Native Resolution
HD (1280x720)
Brightness (ANSI Lumen) - Brightness (ANSI Lumen)
550
Light Source - Type
RGB LED
Contrast Ratio - Contrast Ratio
100,000:1
Features - Digital Keystone Correction
○(Vertical)
Sound - Output
1W + 1W Stereo
Features - Screen Share (Wireless Mirroring with MiraCast supporting device)
○
Projection Lens - Zoom
Fixed
Projection System
DLP
Native Resolution
HD (1280x720)
Brightness (ANSI Lumen)
550
Contrast Ratio
100,000:1
Energy Saving Min. (Bright)
30dB(A)↓
Energy Saving Med.
24dB(A)↓
Energy Saving Max. (Eco)
23dB(A)↓
Uniformity (JBMMA 9 Point)
90%↑
Focus (Auto / Manual)
Manual
Zoom
Fixed
Screen Size
25" ~ 100"
Standard (lens to wall)
40"@1.24m 100"@3.1m
Throw Ratio
1.4
Projection Offset
100%
Type
RGB LED
Life Hours
30,000 Hrs
OSD Languages
Korean / English / French/ Spanish/ German / Rumania / Swedish / Portuguese / Chinese Simplified / polish/ Brazilian Portuguese/ Russian/ Arabic/ Turkish / Taiwanese/ Bulgarian/ Croatian/ Hungarian/ Indonesian/ L-Spanish/ Slovene/ Hindi / Vetnam
Aspect Ratio Control
4:3/Just scan/Set by Pro./ 16:9/Zoom/Cinema Zoom
Output
1W + 1W Stereo
Clear Voice
○ (Clear Voice ll)
Running time
Up to 2.5 hours
Capacity
22.2Wh (3,000mAh x2)
Net Size (mm) (W x D x H)
174 x 116 x 44
Net Weight (kg or g)
650g
Power Consumption (Max.)
55W
Stand-by Power
0.5W↓
Power Supply
Adapter (100V – 240V @ 50~60 Hz)
Operation Temperature
0 ~ 40℃
Digital(HDMI)
1080p/1080i/720p/480p/576p
RGB
up to WSXGA+(1680x1050@60Hz)
Component Video
1080p/1080i/720p/480p/480i/576p/576i
Composite Video
480i/576i
RGB in
○
RGB(PC) Audio in
○
Composite(AV) in
Phone to AV in
Composite(AV) Audio in
Phone to AV in
Component (YPbPr)
RGB to Component in
Component (YPbPr) Audio in
RGB to Component in
Audio out
1 (Φ3.5)
HDMI
1 (MHL)
USB Type-A
1 (USB2.0)
Platform (OS, UI)
Non Smart
Screen Share (Wireless Mirroring with MiraCast supporting device)
○
Bluetooth Sound out
○
Bluetooth AV Sync Control
○
Plug & Play(RGB/DVI/HDMI Auto Source Detection)
○
USB Host (Movie, Music, Photo)
○
File(Office) Viewer
○
Eco Function - Energy Saving Mode
○ (Min/Med/Max)
Eco Function - Sleep Timer
○
Eco Function - Auto Off / Auto Sleep
○
Eco Function - Automatic Standby / Auto Power Off
○
Processor
○
Digital Keystone Correction
○(Vertical)
Auto Keystone
○(Vertical)
Image Flip
○ (Horizontal/Vertical)
Black Level Control
○
Noise Reduction
○
Color Temperature Adjustment
○
Dynamic Contrast (Expert control)
○
Dynamic Color (Expert control)
○
Color Management System (Expert control)
○
Color gamut setting (Expert control)
○
Gamma Correction (Expert control)
○
Quick(Instant) Power on/off
○ (on 10 Sec off 2 Sec)
Store Mode
○
Blank
○
Picture Still
○
Self Diagnosis
○
Cabinet Color
White
Local Key
Joystick
Kensington Lock
○
Leg-Stand
○
Tripod hole (for Tripod, Ceiling mount)
○
Manual (Full or Simple Book)
Simple Book
Quick User Guide (Quick Set-up Guide)
○
Warranty Card
○
Remote Control - Normal
○ (Card)
Conformances(Regulation)
CE, IEC, MIC, USA/Chinese
