55UX340C
55” class (54.64'' diagonal) UX340C Commercial Lite Ultra High Definition TV
/
1/8
55” class (54.64" diagonal) UX340C Commercial Lite Ultra High Definition TV
PANEL
-
- Panel Size
- 55” Class (54.64” diagonal)
- Backlight Type
- Edge
-
- Resolution
- 3840 x 2160 (UHD)
- Frame Rate
- T120Hz
-
- Contrast Ratio
- 1200:1
- Response Time
- 9ms(G to G)
-
- Viewing Angle(HxV)
- 178° x 178°
- Dynamic Contrast Ratio
- 1,000,000:1
-
- Brightness
- 400cd/m2
FEATURES
-
- Remote Diagnosis
- Yes (Self Diagnosis (USB))
- HDMI-CEC
- Yes (without ARC)
-
- HTNG-CEC
- Yes
- Menu
- PDM only
-
- Lock Mode
- Yes
- RJP Interface
- Yes (RS232C,HDMI)
-
- RJP Compatibility
- Yes
- USB
- USB 2.0
-
- USB Auto Play back
- Yes
- Audio Codec
- MP3, AC3, MPEG, AAC,HEAAC, CDDA, LPCM
-
- Auto Off / Auto Sleep
- Yes
- Multi IR Code
- Yes
-
- USB Cloning
- Yes
- Motion Eye Care
- Yes
-
- Moving Picture Playback
- Divx HD (SD/HD/Plus HD)
- Welcome Screen
- Yes (Splash Image)
OTHER
-
- Warranty
- 3-Year Limited Warranty Parts/Labor/Backlight | Extended warranty options are also available
- UPC
- 71919196988
INTERFACE (Side)
-
- USB
- 1 (2.0)
- HDMI In
- 1
BROADCASTING SYSTEM
-
- Analog
- NTSC
- Digital
- ATSC
VIDEO
-
- Real Cinema 24p
- Yes (3:3 pull down)
- Dynamic Color Enhancer
- Yes
-
- Triple XD Engine
- Yes
- Aspect Ratio
- 6 modes ( 16:9, Just scan,Set by program, 4:3,Zoom,Cinema zoom1)
-
- Tru 4K Upscaler
- Yes
AUDIO
-
- Audio Output
- 10W + 10W
- Clear Voice
- Yes
-
- Sound Mode
- 6 Modes (Standard, News, Music, Cinema, Sport, Game)
- Speaker System
- 2.0 ch
-
- Optical Sound Sync
- Yes
- Sound Optimizer
- 3 modes (Normal, Wall-Mount Type, Stand Type)
INTERFACE (Rear)
-
- RF In
- 1
- AV In
- 1 (Sharing with Component in)
-
- PC Audio Input
- 1 (Sharing with Component Audio)
- External Speaker Out
- 1 (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type (GRD,L+,R+), 1W with 8Ω))
-
- Digital Audio Out
- 1 (Optical)
- Component In
- 1
-
- RGB In
- 1 (D-sub 15pin) - PC
- HDMI In
- 1
-
- USB
- 1 (2.0)
CABINET
-
- Bezel Color
- Silver/Black
- VESA™ Compatible
- 300mm x 300mm
-
- WxHxD (with stand)
- 48.8"x30.6"x10.3"
- Weight (With Stand)
- 43.43 lbs
-
- WxHxD (w/o stand)
- 48.8"x28.4"x2.2"
- Weight (Without Stand)
- 39.24 lbs
-
- Carton (W x H x D)
- 52.4"x31.9"x6"
- Bezel Width On (L/R, U, B) (mm)
- 11.7mm, 11.2mm, 14.8mm
-
- Bezel Width Off (L/R, U, B) (mm)
- 9.4mm, 8.9mm, 12.5mm
- Weight (Carton)
- 52.47 lbs
POWER
-
- Stand-by
- <0.5W
- Voltage, Hz
- 100V - 240V, 50/60 Hz
ACCESSORIES
-
- Manual/ESG
- Simple Manual
- Cable
- Power cord (5’1”, 90 Degree Angle Connector)
