KEY FEATURES

  • Direct View LED Display with 2.5 mm Pixel Pitch
  • Brightness Peak 4,000 nits
  • Service Access: Front and Rear
  • IP Rating: IP66
  • Eye-level Pitch
2.5mm Direct View LED Accessible Display with IP66 rating, HDR10/HDR10 Pro Support, & SuperSign CMS
$

Accessible LED

*All images in this page are for illustrative purposes only.

Eye-level Pitch for Outdoor

Unlike pre-existing large-scale screens that are installed at elevated heights, the GSED series has a lower pixel pitch of 2.5 mm, which allows for eye-level accessibility.
*All images in this page are for illustrative purposes only.

Design for Durability and Easy Maintenance

The GSED series corner brackets provide a solid installation that reduce the risk of twisting. Front and rear accessability allow for easy maintenance in various installation environments.
*All images in this page are for illustrative purposes only.

Signal Redundancy Support

The GSED series is designed to support redundancy of signal. With an additional system controller, customers can get continuous operation while the dual controllers can reduce screen failures with bi-directional signal input.
*To use Signal redundancy properly, video transmission system has to be arranged suitably. Please check it with LG engineer to confirm it.

Compatibility with LG Software Solutions

When connected with LG's CVEA system controller, the GSED series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare.
*LG ConnectedCare service differs by region, and is purchased separately. Please contact an LG sales representative in your region for more details.
*Items monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
*Actual GUI may vary in different webOS versions.
*SuperSign CMS purchased separately.

PHYSICAL PARAMETERS

    • Pixel Configuration
    • Single SMD
    • Pixel Pitch (mm)
    • 2.50
    • Module Resolution (W × H)
    • 96 × 108
    • Module Dimensions (W x H, in. / mm)
    • 9.4 x 10.6 / 240 x 270
    • Weight per Module (Ibs. / kg)
    • 2.3 / 1.05
    • No. of Modules per Cabinet (W × H)
    • 2 × 2
    • Cabinet Resolution (W × H)
    • 192 × 216
    • Cabinet Dimensions (W x H x D, in. / mm)
    • 18.9 x 21.3 x 2.8 / 480 x 540 x 70
    • Cabinet Surface Area (ft² / m²)
    • 2.8 / 0.26
    • Weight per Cabinet (Ibs. / kg)
    • 18.7 / 8.5
    • Weight per Square Meter (Ibs./ft² / kg/m²)
    • 6.7 / 32.7
    • Physical Pixel Density (pixels/m²)
    • 160,000
    • Flatness of Cabinet (mm)
    • ±1.0
    • Cabinet Material
    • Al
    • Service Access
    • Front and Rear

OPTICAL SPECIFICATIONS

    • Max Brightness (After Calibration, nits)
    • 4,000
    • Color Temperature (K)
    • 3,500-8,500
    • Visual Viewing Angle (H × V)
    • 160° × 140°
    • Brightness Uniformity
    • 97%
    • Color Uniformity
    • ±0.05 Cx, Cy
    • Contrast Ratio
    • 4,000 : 1
    • Processing Depth (bit)
    • 16 (HDR10, HDR10 Pro)

ELECTRICAL SPECIFICATIONS

    • Power Consumption (W/Cabinet, Max.)
    • 180
    • Power Consumption (W/Cabinet, Avg.)
    • 72
    • Power Consumption (W/m², Max.)
    • 694
    • Heat Dissipation (BTU/h/Cabinet, Max.)
    • 614
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
    • 246
    • Heat Dissipation (BTU/h/m², Max.)
    • 2,368
    • Power Supply (Vac)
    • 100 to 240
    • Frame Rate (Hz)
    • 50 / 60
    • Refresh Rate (Hz)
    • 3,840

OPERATION SPECIFICATIONS

    • LED Lifetime (Half brightness)
    • Up to 100,000 hours
    • Operating Temperature (°F / °C)
    • -22 to 122 / -30 to 50
    • Operating Humidity
    • 0-90% RH
    • IP Rating Front / Rear
    • IP66 / IP66

WARRANTY

    • Warranty
    • 3 Year Limited

CERTIFICATION

    • Certification
    • CE / FCC / ETL

ENVIRONMENT

    • Environment
    • RoHS, REACH

CONTROLLER

    • Controller
    • CVEA

Specification Sheet
