75TR3PJ-B component-copyModelName
CreateBoard

Key Features

Choose your Size

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (75TR3PJ-B)
    ৳
    ৳
    LG Members Price
Total
Add to CompareAdd to CompareRemove Compare

component-OBScountrySelectDesc

See Retailer for Pricing

Limited Quantity Sale

Available QTY 0
  • vip-price-message
    (75TR3PJ-B)
    ৳
    ৳
    LG Members Price
Total
CreateBoard

True Interactivity for
Bringing People Together

When the teacher marks it on the TR3PJ, it is displayed on the students' electronic device screens at the same time. When the teacher marks it on the TR3PJ, it is displayed on the students' electronic device screens at the same time.
* 86 inch
* All images are for illustrative purposes only.
** Video Conferencing Solutions need to be purchased separately.

Multi Touch & Writing

The TR3PJ series can simultaneously use up to 20 points of multi touch. This function offers a lifelike board writing experience and makes collaboration much easier.
Three children are drawing on the TR3PJ at the same time. Three children are drawing on the TR3PJ at the same time.
The screens of students' laptops and teacher's mobile are being shared to the display. The screens of students' laptops and teacher's mobile are being shared to the display.

ScreenShare Pro Upgrade

With the newly upgraded ScreenShare Pro, which enables to show a maximum of six shared screens or a file on a screen in real-time, it has enhanced usability by allowing users to share Chromecast, Airplay and Miracast mirroring on the same network.

* ScreenShare Pro is a Wi-Fi based software and supported by separated application.
** All devices should be connected within the same network.
A teacher is having a class and the screen on the display is being shared to each students' laptop. A teacher is having a class and the screen on the display is being shared to each students' laptop.

Air Class

Air Class supports connecting up to 30 students and offers interactive classes by using mobile devices equipped with web browsers, providing a variety of tools such as voting, answering, and sharing project texts.
Display Power Management function to manage power more efficiently. Display Power Management function to manage power more efficiently.

DPM
(Display Power Management)

By activating DPM function, the display can be set to be on only when there is an input signal, which enables more efficient power management.
Engineering Drawing class with TR3PJ's annotation tool using Un-do and Re-do functions. Engineering Drawing class with TR3PJ's annotation tool using Un-do and Re-do functions.

Annotation Upgrade

At annotation tool mode, ‘Un-do’ and ‘Re-do’ functions provide enhanced user experience. (Annotation tool can be used on any source.)

* Un-do : Moves one step back
Re-do : Moves one step forward
A woman searching for information using the web browser. A woman searching for information using the web browser.

Web Browser

The TR3PJ series supports the web browser* in the Android OS**, so you can search the web easily and quickly, without connecting to an external desktop.

* Network-based Function
** The Android OS is updated to 9.0 ver.
System-on-a chip integrated with Android OS and free apps. System-on-a chip integrated with Android OS and free apps.

All-in-One

The TR3PJ series integrates both Android OS and Free apps into a high performance SoC, without a PC.

Secure Mode

Secured mode disables screen mirroring options for SSP (Screen Share Pro), which is an application that enables screen sharing between mobile devices and the display, to prevent any unauthorized contents to be shown via screen sharing functions in various devices.
Secure Mode for blocking unauthorized contents. Secure Mode for blocking unauthorized contents.
Built-in OPS Slot allows users to connect to an external desktop easily, which provides more expanded functions. Built-in OPS Slot allows users to connect to an external desktop easily, which provides more expanded functions.

Built-in OPS Slot

The TR3PJ series supports OPS slots, allowing you to easily and conveniently mount OPS desktop at the back of the interactive digital board with internal power delivery.
USB is not being able to be connected to a display for security. USB is not being able to be connected to a display for security.

USB Block

The USB Block Mode that helps secure and prevent data from being copied into unauthorized devices in advance, which is essential for being used in space where security is critical.

Partial Capture

Users can select the desired area of the screen to crop the image and store that in internal memory. Also, TR3PJ allows that send cropped images directly to email or note apps.
A woman captures part of the TR3PJ and explains it to the man. A woman captures part of the TR3PJ and explains it to the man.
Three people are gathered in a conference room, having a virtual meeting with other people who are appearing on the screen. Three people are gathered in a conference room, having a virtual meeting with other people who are appearing on the screen.

Bluetooth Connectivity

TR3PJ supports Bluetooth to connect wirelessly to various devices such as speaker, mouse, keyboard, etc. This is optimized for building a hybrid environment so that online and offline meetings and classes can proceed with ease.
The LG employee is remotely monitoring the TR3PJ series installed in a different place. The LG employee is remotely monitoring the TR3PJ series installed in a different place.

Real-time ConnectedCare Service

Maintenance is easy and fast with the optional ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, ensuring the stable operation of clients' businesses.

* The availability of the "ConnectedCare" service differs by region, so please contact the LG sales representative in your region for more details.
Close
PANEL
  • Screen Size
    75"
    Panel Technology
    VA
  • Back Light Type
    Direct
    Aspect Ratio
    16 : 9
  • Native Resolution
    3,840 x 2,160 (UHD)
    Refresh Rate
    60 Hz
  • Brightness
    490nit (wo Glass max),390nit (wo Glass typ), 335nit (wo Glass, min) 450nit (w Glass, max),350nit (w Glass, typ), 300nit (w Glass min)
    Contrast Ratio
    5,000:1
  • Color gamut
    NTSC 72%(TYP.)
    Viewing Angle (H x V)
    178 x 178
  • Color Depth
    8bit+FRC, 1.07Billion colors
    Response Time
    8.5ms (G to G)
  • Surface Treatment(Haze)
    Anti Glare，7Mohs, Haze 25%
    Life Time (Typ.)
    30,000 Hrs (Min.)
  • Operation Hours (Hours/Day)
    16/7
    Portrait / Landscape
    No / Yes
CONNECTIVITY(JACK INTERFACE)
  • Input - Digital - HDMI
    Yes (3), HDCP2.2/1.4
    Input - Audio In
    Yes(1)
  • Input - RS232C IN
    Yes(1)
    Input - RJ45(LAN)
    Yes(1)
  • Input - IR IN
    Yes(1)
    Input - USB
    USB3.0 Type A(4) USB2.0 Type A(1) USB3.1 Type C (1, USB-PD, DP-Alt. Mode)
  • Output - DP Out
    No, HDMI Out (1)
    Output - Audio Out
    Yes(1), Optical O(1)
  • Output - Touch USB
    Yes(2)
    Output - RJ45(LAN)
    Yes(1)
MECHANICAL SPECIFICATION
  • Bezel Color
    Black
    Bezel Width
    17.7/17.7/17.7/45.7mm
  • Weight (Head)
    52.2Kg
    Packed Weight
    64.70Kg
  • Monitor Dimension (W x H x D)
    1710×1020×87mm
    Carton Dimensions(W x H x D) (Box outer size)
    1863×225×1140mm
  • Handle
    Yes
    VESA™ Standard Mount Interface
    800 x 400
KEY FEATURE
  • HW - Internal Memory
    32GB
    HW - Wi-Fi - Built-in
    Yes (Slot type)
  • HW - Power Indicator
    Yes
    HW - Local Key Operation
    Yes
  • SW - webOS ver.
    Android 9.0
    SW - Background Image - Booting Logo Image
    Yes
  • SW - Screen Share
    Yes (Screenshare pro)
    SW - 3rd Party Compatibility - Crestron Inside
    Yes
  • SW - Power - Smart Energy Saving
    Yes
    SW - Power - PM mode
    Yes
  • SW - Power - Wake on LAN
    Yes
    SW - Power - Network Ready
    Yes
  • SW - HDMI-CEC
    Yes
ENVIRONMENT CONDITIONS
  • Operation Temperature
    0 °C to 40 °C
    Operation Humidity
    10% ~90%RH
POWER
  • Power Supply
    AC 100-240V~, 50/60Hz
    Power Type
    Built-In Power
POWER CONSUMPTION
  • Typ.
    TBD
    Max.
    469W
  • BTU (British Thermal Unit)
    TBD
    DPM
    Yes
  • Power off
    0.5W↓
SOUND
  • Speaker
    Yes (12W x 2)
CERTIFICATION
  • Safety
    CB / NRTL
    EMC
    FCC Class “A” / CE
  • ErP / Energy Star
    Yes / No
OPS COMPATIBILITY
  • OPS Type Compatible
    Yes (Slot)
    OPS Power Built In
    Yes
SOFTWARE COMPATIBILITY
  • Signage 365 Care
    Yes
Language
  • OSD
    English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands（Dutch), Norwegian, Polski, Portugues(Europe),Portugues(Brazil)
    Romanian, Russian, Spanish, Swedish, Turkish, Ukrainian, Traditional Chinese, Hungarian, Latvian, Thai
ACCESSORY
  • Basic
    Power Cord 3 M*1, USB Cable (Type A-Type B) 5 M*1, HDMI Cable 3 M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module
SPECIAL FEATURE
  • Touch - Available object size for touch
    Ø3 mm ↑
    Touch - Reponse Time(PC Win10)
    60ms ↓ (Android) 100ms ↓ (Windows)
  • Touch - Accuracy
    ±2mm
    Touch - Interface
    USB2.0
  • Touch - Protection Glass Thickness
    4T (Anti-Glare)
    Touch - Protection Glass Transmission
    87%
  • Touch - Operating System Support
    Windows 7/8/10/WindowsXP/Linux/Mac/Android (WindowsXP/Linux/Mac Support one point touch)
    Touch - Multi touch point
    Max 20 Points
ANDROID SYSTEM
  • SoC
    Quad core A73
    GPU
    Dual Core Mail G51
  • Internal Memory - Storage
    32GB
    Internal Memory - RAM
    4GB
  • Wi-Fi
    802.11a/b/g/n/ac
    LAN
    Gigabit LAN
  • Bluetooth
    Bluetooth 5.0
