55XF3C component-copyModelName

XF3C Series

Discontinued

55XF3C component-copyModelName

XF3C Series

Key Features

Brightness : 3,000 cd/m2 (Typ.)
Life Time : 50,000 hours
Bezel : 9.9 mm (L/R), 12 mm (T/B)
Depth : 106 mm
Interface : HDMI (2) / DP / DVI / RJ45 / IR / RS232C / USB / External speaker out (L/R)

Choose your Size

Add to Compare

component-OBScountrySelectDesc

Key Features

Brightness : 3,000 cd/m2 (Typ.)
Life Time : 50,000 hours
Bezel : 9.9 mm (L/R), 12 mm (T/B)
Depth : 106 mm
Interface : HDMI (2) / DP / DVI / RJ45 / IR / RS232C / USB / External speaker out (L/R)

Choose your Size

Add to Compare

component-OBScountrySelectDesc

component-copyModel-toastMsg

XF3C Series

01_High-Operationing-Temperature_1478220066731

Product Reliability

High Operationing Temperature

Its high reliability under high operating temperatures reduces the material costs of the enclosure.

02_Dust_Humidity-Protection_1478220150078

Product Reliability

Dust & Humidity Protection

The conformal coating enhances circuit board reliability by protecting it from dust, iron shavings, humidity and other harsh conditions.

Outstanding Visibility

Increased Brightness

The brightness has been increased to 3,000 cd/m2 compared to previous models

Outstanding Visibility

Wide Viewing Angle

IPS technology provides better control of the liquid crystals which allows the screen to be vie ed from virtually any angle.

Outstanding Visibility

Color Accuracy

IPS technology displays accurate color for each pixel closest to the original image and reproduces the original color without distortion.

Outstanding Visibility

QWP (Quarter Wave Plate)

FPR (Film-type Patterned Retarder) technology is embedded with a QWP which enables clear visibility even when the viewer is wearing polarized sunglasses.

07_Low-Power-Consumption-Using-The-M_Panel_1478220537958

Cost Effective

Low Power Consumption Using The M+ Panel

The M+ panel offers excellent energy efficiency and cost savings and decreases power consumption by 30 compared to conventional RGB panels.

Cost Effective

Smart Brightness Control

The auto-brightness sensor and preset time scheduler save power whenever possible.

Space Management Efficiency

Slimmer Depth
The slimmer depth saves space for installation and makes the enclosure design slimmer.

10_Real-Time-Remote-Monitoring_1478223822308

Easy Maintenance

Real-Time Remote Monitoring

When an alarm occurs, an email notification is sent through the SNMP using the SuperSign C or SI software. In case a malfunction or error occurs, real-time remote care is available.

11_Saving-System-Log-Files_1478223921115

Easy Maintenance

Saving System Log Files

The XF3C supports log file back-up for fault clarification when the display fails. This allows you to conveniently check when an error has occurred.

Panel

Screen Size

55" Class (54.64" measured diagonally)

Resolution

1,920 x 1,080 (FHD)
Brightness (Typ., cd/m²)

3000

Connectivity

Input

HDMI(2), DP, DVI-D, Audio, USB

Output

DP, External Speaker Out (L/R)
External Control

RS232C (In/Out), RJ45, IR Receiver, Pixel Sensor

Physical Specification

Bezel Width

9.9mm (L/R),12mm (T/B)

Monitor Dimension (W x H x D)

1,235.4 x 709.4 x 106 mm
Weight (Head)

28.5 kg

Environment Conditions

Operation Temperature

0°C to 50°C (w/o Direct Sunlight) / 0°C to 40°C (Direct Sunlight)

Operation Humidity

10 % to 80 %

Power

Power Supply

100-240V~, 50/60Hz

Power Type

Built-In Power

Power Consumption

Typ./Max

280 W / 295 W

Smart Energy Saving

160 W

Standard(Certification)

Safety

UL recognized / CB

EMC

FCC Class "A" / CE / KC / VCCI

Software Compatibility

webOS

webOS 1.0

Content Management Software

SuperSign W
Control and Monitoring Software

SuperSign C

Accessory

Basic

Remote Controller (2 batteries included), Power Cord, IR extension cable/PCB, HDMI Cable, Manual(ESG&EIG)

Optional

KT-SP0, AN-WF500 *Stand is not available

Dimension
- 55XF3C.dwg
- 55XF3C.pdf
Software

To download Software, Please visit the Software Download Page (Click).
Manual

To download Owner’s manual, User guide, Quick set-up guide, Please visit the Manual Download Page (Click).
