Discontinued
24BR650B-C
24” IPS FHD Monitor with USB Type-C™, Daisy Chain & Built-in Speaker
/
24” IPS FHD Monitor with USB Type-C™, Daisy Chain & Built-in Speaker
PANEL
-
- Size
- 24" Class (23.8" diag)
- Panel Type
- IPS
-
- Color Gamut (CIE1976)
- 72%
- Color Depth (Number of Colors)
- 16.7M
-
- Pixel Pitch (mm)
- 0.2745 x 0.2745
- Aspect Ratio
- 16:9
-
- Resolution
- 1920 x 1080
- Brightness (Typ.)
- 250 nits
-
- Contrast Ratio (Original)
- 1000:1
- (DFC)
- 5000000 : 1
-
- Response Time (GTG)
- 5ms
- Viewing Angle (CR≥10)
- 178° / 178°
-
- Surface reatment (Glare/Non Glare)
- Anti Glare ,3H
SIGNAL(INPUT)
-
- DisplayPort
- Yes(1.2)
- HDMI
- Yes (2.0)
-
- [ Jack Location ]
- Vertical
- DisplayPort Out
- Yes
-
- Headphone Out
- Yes
- USB
- USB 3.0 (1 up 4 down, one for quick charging)
-
- Speaker
- Type 2ch Stereo
- Audio output (watt)
- 1.2W x 2
POWER
-
- Type
- Built-in
- Input
- 100~240V (50/60Hz)
-
- Normal On (EPA)
- 14.8W
- Normal On (typ. / outgoing))
- 23W
-
- Sleep Mode (Max)
- 0.5W
- DC Off (Max)
- 0.3W
FREQUENCY
-
- H-Frequency (DVI-D)
- 30 ~ 83kHz
- V-Frequency (DVI-D)
- 56 ~ 75Hz
-
- H-Frequency (HDMI)
- 30~83kHz
- V-Frequency (HDMI)
- PC: 56~75Hz, AV: 50~61Hz
-
- H-Frequency (DisplayPort)
- 30~83kHz
- V-Frequency (Display Port)
- 56~75Hz
-
- DVI-D
- 1920 x 1080
- DisplayPort
- 1920 x 1080
-
- HDMI
- 1920 x 1080
- DisplayPort Out
- Dependent on connected display resolution
CONTROL KEY
-
- Key Number
- 7
- Key Description
- MENU, OK/INPUT, POWER
-
- Key Type
- Tact
- LED Color (On Mode)
- White
-
- LED Color (Power save mode)
- LED OFF
- [ Key Location ]
- Front
LANGUAGE
-
- Country
- English, Germanic, French, Spanish, Italian, Swedish, Finnish, Portuguese, Polish, Russian, Greek, Chinese, Japanese, Korean, Ukrainian, Portuguese (Brazil), Hindi, Tranditional Chinese
- Number of Language
- 17
SPECIAL FEATURES
-
- Picture Mode
- Yes
- Ratio
- Yes
-
- Reader Mode
- Yes
- DDC/CI
- Yes
-
- HDCP
- Yes (1.4)
- Key Lock
- Yes
-
- Plug & Play
- Yes
- Response Time
- Yes
-
- Color Calibrated
- Yes
- Dual Control
- Yes
-
- Flicker Safe
- Yes
- Off Timer
- Yes
-
- Six Axis Control
- Yes
- Smart Energy Saving
- Yes (Conserve energy by using luminance compensation algorithm)
-
- Super Resolution+
- Yes
- Special Feature - OSC (On Screen Control / Screen Split)
- Yes
-
- Power Charge
- Yes
COLOR
-
- Front / Back Cover / Stand / Base
- Black (Texture)
STAND
-
- Base Detachable
- Yes
- Tilt (Angle)
- -5° ~ 25°
-
- Swivel (Angle)
- Yes (±30°)
- Height range (mm)
- 130mm
-
- Down Height (mm)
- 112.5mm
- Pivot
- Yes (Bi-directional, 90º)
CABINET
-
- W x D x H (With Stand)
- 21.2" x 10" x 21.5"
- W x D x H (Without Stand)
- 21.2" x 1.9" x 12.7"
-
- Box
- 24.1" x 19.3" x 7.2"
- VESA / Wall Mount
- 100mm x 100mm (Wall mount)
-
- Weight (with Stand)
- 16.3 lbs
- Weight (Without Stand)
- 8.1 lbs
-
- Box Weight
- 18.1 lbs
STANDARD
-
- TCO (Ver.)
- Yes (7.0)
- UL(cUL)
- Yes
-
- TUV-GS
- Yes
- TUV-Ergo
- Yes
-
- CB
- Yes
- FCC-B
- Yes
-
- CE
- Yes
- EPA
- Yes (8.0)
-
- Windows
- Win 10
- ROHS, REACH
- Yes
-
- PVC-Free
- Yes
ACCESSORIES
-
- Power Cord
- Yes
- DisplayPort
- Yes
-
- HDMI
- Yes
- CD (Manual / Software)
- Yes (Manual, Driver)
OTHER
-
- UPC
- 7 19192 60909 9
- Warranty
- 3-Year Limited Warranty (Parts/Labor/Backlight)
