KEY FEATURES

  • Brightness : 350 cd/m2
  • Bezel : Top/Left/Right 11.9 mm (Bottom 18.0 mm)
  • Depth : 38.6 mm
  • Interface : HDMI, DVI, DP, RGB, RJ45, IR, RS232C, SD Card, USB
SM3C Series

PANEL

    • Screen Size
    • 43"
    • Resolution
    • 1,920 x 1,080 (FHD)
    • Brightness
    • 350cd/m2
    • Orientation
    • Portrait & Landscape

CONNECTIVITY

    • Input
    • HDMI, DP, DVI-D, RGB, Audio in
    • Output
    • DP, Audio, External Speaker out
    • External Control
    • RS232C, RJ45, IR receiver, Pixel Sensor, USB 3.0, SD card

Physical Specification

    • Bezel Width
    • 11.9 mm (T/R/L), 18 mm (B)
    • Monitor Dimension (W x H x D)
    • 969.6 x 563.9 x 38.6 mm
    • Weight (Head)
    • 9.8 kg
    • VESA™ Standard Mount Interface
    • 300mm x 300mm

ENVIRONMENTAL CONDITIONS

    • Operation Temperature
    • 0°C to 40°C
    • Operation Humidity
    • 10 % to 80 %

POWER

    • Power Supply
    • 100-240V~, 50/60Hz
    • Power Type
    • Built-in Power

Standard (Certification)

    • Safety
    • UL / cUL / CB / TUV / KC
    • EMC
    • FCC Class "A" / CE / KCC

MEDIA PLAYER COMPATIBILITY

    • OPS Type Compatible
    • Yes
    • External Media Player Attatchable
    • Yes (MP500/MP700)

SOFTWARE COMPATIBILITY

    • SuperSign-w lite
    • Yes
    • SuperSign-c
    • Yes

Accessory

    • Basic
    • Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover
    • Optional
    • Speaker (SP-5000), Stand (ST-432T), Pixel sensor (KT-SP0), Media player, Wall bracket (LSW230B), VESA Adapter (AM-B220S), OPS Kit (KT-OPSA), HDBaseT (EB-B100)
