86” IPS UHD Ultra Stretch Digital Display (3,840x600) with Multi Screen Mode & IP5x Certified
DISPLAY
-
- Screen Size
- 86"
PANEL
-
- Screen Size
- 86"
DISPLAY
-
- Panel Technology
- IPS
PANEL
-
- Panel Technology
- IPS
- Aspect Ratio
- 58:9
DISPLAY
-
- Back Light Type
- Direct
PANEL
-
- Native Resolution
- 3,840 x 600
DISPLAY
-
- Aspect Ratio
- 58:9
- Native Resolution
- 3840 x 600
PANEL
-
- Brightness (Typ., nits)
- 500
- Contrast Ratio
- 1,100:1
DISPLAY
-
- Refresh Rate
- 60Hz
PANEL
-
- Viewing Angle (H x V)
- 178 x 178
DISPLAY
-
- Brightness (Typ.)
- 500nits
PANEL
-
- Response Time
- 8ms (G to G)
DISPLAY
-
- Contrast Ratio
- 1100:1
PANEL
-
- Surface Treatment (Haze)
- 10%
DISPLAY
-
- Dynamic CR
- 500,000:1
- Color gamut
- NTSC 72%
PANEL
-
- Lifetime
- 50,000 Hrs (Typ.)
DISPLAY
-
- Viewing Angle (H x V)
- 178° x 178°
PANEL
-
- Operation Hours
- 24 Hrs/7 Days
- Orientation
- Landscape & Portrait
DISPLAY
-
- Color Depth
- 10bit, 1.07 Billion colors
- Response Time
- 8ms (G to G)
CONNECTIVITY
-
- Input
- HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
- Output
- DP, Audio
DISPLAY
-
- Surface Treatment (Haze)
- 10%
CONNECTIVITY
-
- External Control
- RS232C In/out, RJ45 (LAN) In/out, IR In
DISPLAY
-
- Lifetime
- 50,000 Hrs (Typ.)
- Operation Hours (Hours/Day)
- 24/7
MECHANICAL SPECIFICATION
-
- Bezel Color
- Black
DISPLAY
-
- Portrait / Landscape
- Yes/Yes
MECHANICAL SPECIFICATION
-
- Bezel Width
- 4.4 mm (L/R), 5.9 mm (T/B)
- Monitor Dimension (W x H x D)
- 85.0” x 13.7” x 3.2” / 2,158.3 x 348.5 × 81.7 mm
CONNECTIVITY
-
- HDMI IN
- Yes (x3), HDCP2.2
MECHANICAL SPECIFICATION
-
- Weight (Head)
- 45.1 lbs. / 20.5kg
CONNECTIVITY
-
- DP In
- Yes (x1), HDCP2.2
- DVI-D In
- Yes (x1), HDCP1.4
MECHANICAL SPECIFICATION
-
- Carton Dimensions (W x H x D)
- 90.2” x 23.6” x 9.0” / 2,290 x 599 x 228 mm
CONNECTIVITY
-
- Audio In
- Yes (x1)
MECHANICAL SPECIFICATION
-
- Packed Weight
- 84.2 lbs. / 38.2kg
- Handle
- Yes
CONNECTIVITY
-
- RS232C In
- Yes (x1)
CONNECTIVITY
-
- RJ45 (LAN)
- Yes (x1)
MECHANICAL SPECIFICATION
-
- VESA™ Standard Mount Interface
- 23.6” x 7.9” / 600 x 200 mm
CONNECTIVITY
-
- IR In
- Yes (x1)
ENVIRONMENT CONDITIONS
-
- Operation Temperature
- 32°F to 104°F / 0°C to 40°C
- Operation Humidity Range
- 10% to 80%
CONNECTIVITY
-
- USB in
- USB2.0 Type A (x2)
CONNECTIVITY
-
- DP Out
- Yes (x1), Input: HDMI/DVI/DP
POWER
-
- Power Supply
- 100-240V~, 50/60Hz
CONNECTIVITY
-
- Audio Out
- Yes (x1)
- RS232C OUT
- Yes (x1)
POWER CONSUMPTION
-
- Typ./Max.
- 220W/240W
- Smart Energy Saving
- 100W
MECHANICAL
-
- Bezel Color
- Black
- Bezel Width
- T/R/L/B: 5.9/4.4/4.4/5.9 mm
STANDARD (CERTIFICATION)
-
- Safety
- CB/NRTL
MECHANICAL
-
- Weight (Head)
- 45.2 lbs/20.5kg
STANDARD (CERTIFICATION)
-
- EMC
- FCC Class "A"/CE/KC
- ErP/Energy Star
- Yes (EU Only)/No
MECHANICAL
-
- Shipping Weight
- 84.2 lbs/38.2kg
MEDIA PLAYER COMPATIBILITY
-
- OPS Type Compatible
- Yes (Piggyback)
MECHANICAL
-
- Monitor Dimension (W x H x D)
- 85.0 x 13.7 x 3.2 in/2158.3 x 348.5 x 81.7 mm
- Shipping Dimensions (W x H x D)
- 90.2 x 23.6 x 9.0 in/2290 x 599 x 228 mm
SOFTWARE COMPATIBILITY
-
- Content Management Software
- SuperSign CMS
- Control and Monitoring Software
- SuperSign Control/Control+
MECHANICAL
-
- Handle
- Yes
SOFTWARE COMPATIBILITY
-
- Signage365Care
- Yes
MECHANICAL
-
- VESATM Standard Mount Interface
- 600 x 200
FEATURES
-
- Internal Memory
- 8GB
ACCESSORY
-
- Basic
- Remote Controller, Power Cord, DP Cable, RS-232C Cable, IR/Light Sensor Receiver, Manual
- Optional
- OPS Kit (KT-OPSF)
FEATURES
-
- Built-in Wi-Fi
- Yes
- Temperature Sensor
- Yes
-
- Auto Brightness sensor
- Yes
- Current Sensor
- Yes
-
- Local Key Operation
- Yes
- Local Contents Scheduling
- Yes
-
- Group Manager
- Yes
- USB Plug & Play
- Yes
-
- Fail over
- Yes
- Booting Logo Image
- Yes
-
- No Signal Image
- Yes
- RS-232C Sync
- Yes
-
- Local Network Sync
- Yes
- PBP
- Yes (x4)
-
- Screen Rotation
- Yes
- External Input Rotation
- Yes
-
- Tile Mode Setting
- Yes (Max. 15X15)
- Setting Data Cloning
- Yes
FEATURES
-
- SNMP
- Yes
FEATURES
-
- ISM Method
- Yes
- Auto Set ID
- Yes
-
- Status Mailing
- Yes
- Control Manager
- Yes
-
- Crestron Inside
- Yes
- Smart Energy Saving
- Yes
-
- PM mode
- Yes
- Wake on LAN
- Yes
-
- Beacon
- Yes
- HDMI-CEC
- Yes
-
- webRTC
- Yes
- OPS type compatible
- Yes (Piggyback)
ENVIRONMENT
-
- Operation Temperature
- 32°F to 104°F/0°C to 40°C
- Operation Humidity
- 10% to 80%
-
- Durability Rating (Dust)
- IP5x
POWER
-
- Power Supply
- 100-240 Vac, 50/60Hz
- Power Type
- Built-in Power
-
- Typical Power Consumption
- 220W
- Max Power Consumption
- 240W
-
- Typical Power Consumption per Hour
- 751 BTU/Hr
- Max Power Consumption per Hour
- 819 BTU/Hr
-
- Smart Enegy Saving
- 100W
- DPM
- 0.5W
-
- Power Off
- 0.5W
CERTIFICATIONS
-
- FCC Class A (Regulatory)
- Yes
- CE (Regulatory)
- Yes
-
- ErP (Energy Efficiency)
- Yes
SOFTWARE COMPATIBILITY
-
- SuperSign CMS
- Yes
- SuperSign Control / Control+
- Yes/Yes
-
- SuperSign WB
- Yes
- SuperSign Media Editor
- Yes
-
- LG ConnectedCare
- Yes
- *
- Not compatible with webOS Signage ecosystem.
Languages
-
- On-screen Display Languages
- English, French, German, Spanish, Italian, Korean , Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Japanese, Russian, Portugues (Europe), Dutch, Czech, Greek, Arabic
ACCESSORIES
-
- Basic
- Remote Controller (including battery 2ea), Power Cord, DP able, RS-232C Cable, IR/Light sensor receiver, Manual
- Optional
- OPS Kit (KT-OPSF)
