KEY FEATURES

  • IPS Dual FHD (3,840 x 1,080) delivers great color
  • 32:9 Aspect Ratio creates a large viewing area
  • 700 nits Brightness for great viewing
  • Built-in WiFi, Temperature Sensor, & Auto Brightness Sensor
  • Operates 24/7 so your important messages are always seen
  • Orient in landscape or portrait mode to deliver the perfect message
88” IPS Dual FHD Ultra Stretch Signage with a 32:9 aspect ratio

PANEL

    • Screen Size
    • 88"
    • Panel Technology
    • IPS
    • Aspect Ratio
    • 32:9
    • Native Resolution
    • 3,840 x 1,080 (Dual FHD)
    • Brightness (Typ)
    • 700 nits
    • Contrast Ratio
    • 1,100:1(Typ)
    • Dynamic CR
    • 500,000:1 (Typ)
    • Viewing Angle (H x V)
    • 178° x 178°
    • Response Time (G to G, Typical)
    • 8ms
    • Surface Treatment
    • AGLR (Haze 3%)
    • Lifetime
    • 50,000 Hrs (Typ.)
    • Operation Hours
    • 24Hrs / 7Days
    • Orientation
    • Landscape & Portrait

CONNECTIVITY

    • Input
    • HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
    • Output
    • DP, Audio
    • External Control
    • RS232C In/out, RJ45 In/out, IR In

MECHANICAL

    • Bezel Color
    • Black
    • Bezel Width
    • 4.4 mm (L/R), 5.9 mm (T/B)
    • Dimensions
    • 85" x 24.1" x 3.3" / 2,158.3 x 611.2 x 84.8 mm
    • Weight
    • 74.7 lbs / 33.9 kg
    • Shipping Dimensions
    • 89.5" x 28.2" x 8.3" / 2,274 x 717 x 212 mm
    • Shipping Weight
    • 114 lbs / 51.7 kg (Pallet included)
    • Handle
    • Yes
    • VESA™ Standard Mount Interface
    • 600 x 400 mm

SPECIAL FEATURES

    • Special Features
    • Internal Memory 8GB(System 4GB, Available 4GB), Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, USB Auto Playback, Local Contents Scheduling, Group Manager, Failover, Image Customization (Booting Logo, No Signal), Content Sync.(RS-232C/Local Network), PBP(4), Play via URL, OSD/Content Rotation, Tile Mode Setting (Max. 15×15), Setting Data Cloning (RS-232C/Network/USB), Crestron Connected®1), Control Manager, Smart Energy Saving, DPM, PM Mode, Wake on LAN, HDMI-CEC2), webRTC, SI Server Setting

ENVIRONMENT CONDITIONS

    • Operation Temperature Range
    • 32° F to 104° F / 0° C to 40° C
    • Operation Humidity Range
    • 10% to 80%

POWER

    • Power Supply
    • 100-240V~, 50/60Hz
    • Power Type
    • Built-in Power
    • Power Consumption (Typ./Max.)
    • 450W / 530W
    • Power Consumption (Smart Energy Saving)
    • 210W

CERTIFICATIONS

    • Safety
    • IEC 60950-1/EN 60950-1/UL 60950-1
    • EMC
    • FCC Class "A" / CE / KC
    • ErP / Energy Star
    • Yes / N/A

Compatibility

    • OPS Type Compatible
    • Yes
    • Content Management Software
    • SuperSign CMS³
    • Control and Monitoring Software
    • SuperSign Control/ Control+³
    • Signage365Care
    • Yes

Warranty & Other

    • Basic Accessories
    • Remote Controller, Power Cord, DP (2.6M), RS-232C Cable (3M)
    • Optional Accessories
    • KT-OPSA(OPS Kit)
    • Warranty
    • 3 Year Limited Warranty
    • UPC
    • 1 95174 00987 1
