Discontinued 98UH5E-B

UH5E Series

LG UH5E Series, 98UH5E-B left 45 degree angle , 98UH5E-B, thumbnail 3

LG UH5E Series, 98UH5E-B left, 98UH5E-B, thumbnail 4

LG UH5E Series, 98UH5E-B display, 98UH5E-B, thumbnail 5

LG UH5E Series, 98UH5E-B display, 98UH5E-B, thumbnail 6

LG UH5E Series, 98UH5E-B display, 98UH5E-B, thumbnail 7

LG UH5E Series, 98UH5E-B display, 98UH5E-B, thumbnail 8

98" 86" 75" 65" 55" 49"

Inquiry to Buy

Add to Wishlist

Add to Compare

EXTENDEDCARE PLANS

KEY FEATURES

Brightness(Typ.) : 500 cd/m²
Bezel : 14.9 mm (Even, Off-Bezel)
Depth : 57.9 mm (without Handle and Logo)
Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR

Discontinued 98UH5E-B

UH5E Series

KEY FEATURES

Brightness(Typ.) : 500 cd/m²
Bezel : 14.9 mm (Even, Off-Bezel)
Depth : 57.9 mm (without Handle and Logo)
Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR

98" 86" 75" 65" 55" 49"

Add to Wishlist

Add to Compare

Inquiry to Buy

EXTENDEDCARE PLANS

UH5E Series

Vibrant Colors and Powerful Performance Bring Content

With superb picture quality and cutting-edge intelligence, the UH5E series enlivens colors without the aid of peripherals. Its quality and brightness are enough to capture the attention of passersby. Moreover, its convenient advanced usability allows users to effortlessly control and manage the display.

Superior Picture Quality

True Color, Immersive View

The UH5E series is large enough to display content and get undivided attention from various viewers. LG IPS panel features a wide range of angle to deliver clear content regardless of the position of viewers. Each pixel in the IPS panel reproduces image colors true-to-life, without distortion.
Vivid Color Details with Ultra HD

The UHD resolution allows users to view details even when zooming in on the display, with four times higher definition than FHD. The UH5E ensures stable UHD video playback with HEVC^{(High Efficiency Video Coding)}.

Powerful webOS Smart Signage Platform

Easy Content Management

The embedded CMS^{(Content Management System)} allows you to create and edit content using internal/external sources as well as set playlists to play at the desired schedule without the need for a separate PC. Thanks to the intuitive GUI and a menu structure based on usage scenarios, content management has been made much easier

Powerful webOS Smart Signage Platform

Simple Group Management

The embedded Group Manager makes a master display work as a server and manage other displays¹⁾ connected on the same network. This way you can group and control multiple displays in your place of business and distribute playlists to them all at once, using input devices such as a remote control.

Powerful webOS Smart Signage Platform

Various Sensor Applications

LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc. via USB plug-in. The overall cost of ownership is reduced as there’s no need to purchase additional software or media players for creating value-added solutions.

Powerful webOS Smart Signage Platform

Multi Screen Mode

PBP(Picture-By-Picture) features multi screen in a single display with upto 4 input sources while PIP(Picture-In-Picture) supports playing both main screen and sub screen at the same time with various layouts. This gives great flexibility to allocate space for each content souce.

Easy Maintenance

Real-Time Monitoring & Control

Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple displays in different locations in realtime. It is available on internet-connected devices, allowing you to flexibly and
rapidly respond to emergency situations anywhere.

Easy Maintenance

Real-time ConnectedCare Service

Maintenance is easy and fast with the optional ConnectedCare* service, a cloud service solution provided by LG. It remotely manages the status of displays in client workplaces for fault diagnosis and remote-control services, enabling the stable operation of clients' businesses.

*ConnectedCare is the brand name of LG Signage365Care Service. Availability differs by region.

Wireless Solution

Content Sharing
Content Mirroring among devices is more convenient on a Wi-Fi network.
Real-time Promotion
With Beacon and BLE^{(Bluetooth Low Energy)}, shop managers can provide coupons and information in real-time.

Wireless Solution

Wireless Access Point

The UH5E series operates as a virtual router which can be an wireless access point for mobile devices.

High Compatibility

Compatibility with AV Control System

The UH5E series has been certified Crestron Connected^Ⓡ for a higher level of compatibility with professional AV controls to achieve seamless integration and automated control¹⁾, boosting business management efficiency.

High Compatibility

Compatibility with Video Conference System

For the optimum visual meeting, the UH5E has certified its compatibility with Cisco Spark Room Kits, a system that offers powerful and integrated control¹⁾ for a smarter video conference, eliminating a waste of time to set up the picture quality or to change input on incoming calls.

Space-efficient Design

Slim and Tidy in Appearance

Although UH5E series is a large-sized display, the product still has a slim depth, a feature that allows easy installation by using less space. An immersive view is attained while maintaining a sleek look.

Space-efficient Design

Detachable Logo & Built-in Speaker

The detachable logo allows for installation in the desired orientation in landscape or portrait mode, making it easy for the user to arrange the signage. Also, sounds can be played from built-in speakers¹⁾, giving advertisements greater impact.

Print Download Spec Sheet

PANEL

- Panel Size
- 98"
- Panel Technology
- IPS
- Resolution
- 3840 x 2160 (UHD)
- Contrast Ratio
- Fri Feb 23 04:01:00 KST 1900
- Response Time
- 8ms (G to G)
- Brightness
- 500 nits
- Aspect Ratio
- 16:9
- Viewing Angle (H x V)
- 178°/178°
- Orientation
- Landscape & Portrait
- Lifetime (Typ.)
- 50,000 Hrs
- Operation Hours
- 24 Hrs
- Surface Treatment (Haze)
- Haze 1%

CONNECTIVITY

- Input
- HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)
- Output
- DP, Audio (Off/Fixed/Variable), External Speaker
- External Control
- RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In

PHYSICAL SPECIFICATIONS

- Bezel Color
- Black
- Bezel Width
- 14.9mm (Even, Off-Bezel)
- Monitor Dimension (W x H x D)
- 86..3" x 49.1" x 2.7" / 2,191.8 x 1,246.8 x 69.4 mm (without Handle)
- Weight (Head)
- 194 lbs / 88 kg
- Carton Dimensions (W x H x D)
- 92.2" x 54.6" x 15.8" / 2,342 x 1,386 x 402 mm
- Packed Weight
- 271.2 lbs / 123 kg
- VESA TM Standard Mount Interface
- 800 x 400 mm
- Handle
- Yes

KEY FEATURES

- Yes
- Yes Internal Memory 8GB (System 4GB + Available 3.6GB), Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Current Sensor, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Image Customization, Failover, Content Sync (RS232C, Local Network), Screen Share, Play via URL, OSD Rotation, Content Rotation, PIP/PBP(4), Tile Mode Setting (Max 15x15), Setting Data Cloning, Firmware Update by Network, SNMP 1.4, ISM Mode, Crestron Connected1, Cisco Compatibility 2, Beacon, HDMI-CEC 3, SI Server Setting, webRTC

ENVIRONMENTAL CONDITIONS

- Operating Temperature Range
- 32°F to 104°F / 0°C to 40°C
- Operating Humidity Range
- 10% to 80%

POWER

- Power Supply
- 100-240V~, 50/60Hz
- Power Type
- Built-in Power
- Smart Energy Saving
- 294W
- Power Consumption (Typ./Max)
- 420W/560W

SOUND

- Speaker
- -

STANDARD CERTIFICATIONS

- Safety
- CB / NRTL
- EMC
- FCC Class "A"/CE/KC
- ErP
- Yes (EU Only)

MEDIA PLAYER COMPATIBILITY

- OPS Type Compatible
- No

SOFTWARE COMPATIBILITY

- Content Management Software
- SuperSign CMS
- Control and Monitoring Software
- SuperSign Control/Control+

ACCESSORIES

- Optional
- Speaker (SP-2200)
- Basic
- Remote Controller, Power Cord, QSG, IR/Light Sensor Receiver, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender, EYE-BOLT

OTHER

- UPC
- 719192624597

WARRANTY

- Limited Warranty
- 3-Year Limited Warranty
