110" 98"
  • Enter ZIP for Estimated Delivery
Add to Cart
Add to Wishlist
EXTENDEDCARE PLANS

KEY FEATURES

  • 98" UHD (3840x2160) ADS Display
  • 500 nits Brightness
  • Large Viewing Angles 178° × 178° & Stunning colors with DCI-P3 88%
  • LG webOS™ 6.0, Pro:Idiom & SuperSign Compatible
  • Compatible with AV Control System, Supports Crestron Connected®, Cisco Certified
  • Life time up to 50,000 hours, Operating 16/7 (Hours/Days)
98" UMK5-B UHD Signage with webOS™ 6.0, Pro:Idiom, Supports Crestron Connected®, Cisco Certified, SuperSign Compatible
$ 8,958.00
Pause

UHD Large Screen Digital Signage with LG webOS™

*Image simulation for illustration purposes only.

Ultra HD Resolution

UHD resolution is 4 times higher than FHD, which makes the color and details of the contents more vivid and realistic. In addition, the IPS Panel allows for wider viewing angles and provides clearer content with no distortion.

Clear Content Delivered with 500 nits Brightness

With a brightness rating of 500 nits the UM5K series displays deliver brilliant content and attracts attention, making these displays an ideal choice for a wide variety of businesses, including retail and corporate
*Image simulation for illustration purposes only.

High-Performance with webOS™

LG webOS™ platform enhances user convenience with intuitive GUI and simple app development tools.

Built-in Speaker

Enrich content with sound effects from built-in speakers.

*Internal Built-in Speaker Support (L/R max 10 W)
*Image simulation for illustration purposes only.

Slim Design

The slim design of the UM5K allows it to be installed closer to the wall, helping to create an immersive experience and sophisticated look.
*Image simulation for illustration purposes only.

Mobile Content Management

Create a store profile and get template recommendations using the LG Promota* app. Users can customize templates as needed and easily create and manage content not only on PCs but also on mobile devices.

*LG Promota is can be downloaded from the App Store and Google Play store.
*Image simulation for illustration purposes only.

Compatible with AV Control System

The UM5K series supports Crestron Connected® for compatibility with professional AV controls to achieve seamless integration and automated network-based control.

*Network based control
*Image simulation for illustration purposes only.

LG SuperSign™ Solutions

SuperSign™ is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.

Some SuperSign software solutions require purchase. Visit https://www.lg.com/us/business/display-solutions/supersign
*Image simulation for illustration purposes only.

PANEL

    • Screen Size
    • 98"
    • Panel Technology
    • ADS
    • Back Light Type
    • Direct
    • Aspect Ratio
    • 16:9
    • Native Resolution
    • 3,840 × 2,160 (UHD)
    • Refresh Rate
    • 60 Hz
    • Brightness
    • 500 nits (Typ.)
    • Contrast Ratio
    • 1,200:1
    • Dynamic CR¹
    • 200,000:1
    • Color Gamut
    • DCI-P3 88%
    • Viewing Angle (H × V)
    • 178° × 178°
    • Color Depth
    • 1.07 Billion Colors (8 bits + FRC)
    • Response Time
    • 8 ms (G to G)
    • Surface Treatment (Haze)
    • 25%
    • Lifetime
    • Up to 30,000 Hrs.
    • Operation Hours (Hours / Day)
    • 16 / 7
    • Portrait / Landscape Orientation
    • Yes / Yes

CONNECTIVITY

    • Input
    • HDMI x3 (HDMI1/2: HDCP 2.2/1.4, HDMI3), DisplayPort (HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio In, RS-232C (4 Pin 3.5mm), RJ45 (LAN), IR In, USB 2.0 Type-A
    • Output
    • HDMI Out, Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP, DVI / Output HDMI)

MECHANICAL SPECIFICATION

    • Bezel Color
    • Black
    • Bezel Width
    • 17 mm (Even Bezel)
    • Weight
    • 172 lbs. / 78 kg
    • Shipping Weight
    • 231.5 lbs. / 105 kg
    • Dimensions (W × H × D)
    • 86.5 x 49.3 x 3.1 in. 2,198× 1,253 × 79.5 mm
    • Shipping Dimensions (W × H × D)
    • 105.5 x 1730 x 320 in. 2,680 × 1,730 × 320 mm
    • Handle
    • Yes
    • VESA™ Standard Mount Interface
    • 800 × 400 mm

SPECIFICATIONS

    • Key Features
    • Internal Memory (eMMC) 16 GB, Built-in Wi-Fi, Sensor (Temperature Sensor, Auto Brightness Sensor, Acceleration (Gyro) Sensor), Power Indicator, Local Key Operation, webOS 6.0, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Image (Booting Logo Image, No Signal Image), Sync (RS-232C Sync, Local Network Sync), PIP, PBP (4), Screen Share, Video Tag (4), Play via URL, Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Datav Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Cisco Certi, Crestron Inside, Smart Energy Saving, PM Mode, Wake on LAN, Network Ready, Beacon, HDMI-CEC2 , SI Server Setting, webRTC, Pro:Idiom
    • Software Compatibility
    • SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud, LG Promota App, Mobile CMS, LG ConnectedCare
    • Language
    • English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Turkish, Arabic, Polski

ENVIRONMENT CONDITIONS

    • Operation Temperature
    • 32°F to 104°F 0°C to 40°C
    • Operation Humidity
    • 10% to 80%

POWER

    • Power Supply
    • 100-240 Vac, 50/60 Hz
    • Power Type
    • Built-In Power

SOUND

    • Speaker (Built-in)
    • 10 W × 2

POWER CONSUMPTION

    • Typ. / Max.
    • 430 W / 560 W
    • BTU (British Thermal Unit)
    • 1,467 BTU/Hr (Typ.), 1,911 BTU/Hr (Max.)
    • Smart Energy Saving (~70%)
    • 301 W
    • DPM
    • 0.5 W
    • Power off
    • 0.5 W

CERTIFICATIONS

    • Safety
    • CB / NRTL
    • EMC
    • FCC Class "A" / CE / KC
    • ErP (Environmental)
    • Yes (New ErP)

Warranty & Other

    • Warranty
    • 3 Year Limited
    • UPC
    • 1 95174 06122 0
    • Accessories
    • Remote Control, Power Cord, QSG, IR/Light Sensor Receiver, Regulation Book, 3.5mm to RS-232C Adapter
