KEY FEATURES

  • 1.88 mm Pixel Pitch (Single SMD configuration)
  • TAA Complaint with 3 Year Limited Warranty
  • Compatible with 27" LSBE model for flexible design
  • Durable frame & easy maintenance
  • Compatible with CVBA system controller
  • Compatible with LG SuperSign software & LG ConnectedCare services
1.88 mm LSBF Value Series TAA Complaint Direct View LED
$

LSBF Indoor Direct View LED Series

*Images are simulated for illustration purposes only.

Brightness

With a great brightness of 600 nits, it clearly delivers content and attracts public attention, making it ideal for achieving bright indoor visibility.
*Images are simulated for illustration purposes only.

54" & 27" Combination Installation Available

The LSBF (54") and LSBE (27") Value Series models, sharing the same product platform, provide flexible matrix combinations for various spatial configurations. The compatibility between the 54" and 27" models enables versatile sizing options according to space requirements, allowing for installation.
*Images are simulated for illustration purposes only.

Durable Frame Design

LSBF incorporates an aluminum cabinet that enhances durability, and its high-strength frame, surpassing that of plastic, allows for stable operation.

Improved Flatness and Easy Maintenance

LSBF is composed of four LSBE modules that form one cabinet with two modules each, allowing it to create a seamless screen. Also, it allows for easy maintenance.

Easy Replacement and Maintenance

Upgrade your existing 54-inch LCD video wall to the latest technology and LED display without having to secure additional space.
*Images are simulated with illustration purposes only. The product can be installed using VESA wall-mount (600×400) and screws. The VESA wall-mount or any other wall-mounts are sold separately.

More Secure Maintenance with the Use of Safety Wire

When removing a module from the cabinets, the safety wire helps secure maintenance by preventing screen and module drops.

Flame Spread Protection

LSBF is compliant with the standard for assessing flame spread, receiving a Class C rating according to the EN 13501-1:2018 test. With its fire resistance, LSBF contributes to the safety of your space.
*The test was conducted by SGS-CSTC Standards Technical Services (Shanghai) Co., LTD on Aug. 21 to 24, 2023, in accordance with the EN 13501-1:2018 standard. The LED module with product number (LSBF XX-XXX) was used as the test subject. The test results confirmed its compliance with the EN 13501-1:2018 Class C-s2, d0 rating.

Compatibility with LG Software Solutions

When connected with LG's CVBA system controller, the LSBF series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.
*The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
*The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
*Actual GUI may vary in different webOS versions.
*LG Software solutions needs to be purchased separately.

PHYSICAL PARAMETERS

    • Pixel Configuration
    • Single SMD
    • Pixel Pitch (mm)
    • 1.88
    • Module Resolution (W × H)
    • 160 × 180
    • Module Dimensions (W × H)
    • 11.8 x 13.3 x 0.5 in. 300 × 337.5 × 13 mm
    • Weight per Module
    • 2.1 lbs. / 0.95 kg
    • No. of Modules per Cabinet (W × H)
    • 4 x 2
    • Cabinet Resolution (W × H)
    • 640 × 360
    • Cabinet Dimensions (W × H × D)
    • 47.2 x 26.6 x 2.8 in. / 1,200 × 675 × 72 mm
    • Cabinet Surface Area (m²)
    • 0.81
    • Weight per Cabinet (kg/Cabinet)
    • 23
    • Weight per Square Meter (kg/m²)
    • 28
    • Physical Pixel Density (pixels/m²)
    • 284,089
    • Flatness of Cabinet (mm)
    • ±0.3
    • Cabinet Material
    • Die-cast Aluminum
    • Service Access
    • Front

OPTICAL SPECIFICATIONS

    • Max. Brightness (After Calibration, nits)
    • 600
    • Color Temperature (K)
    • 3,200-9,300
    • Visual Viewing Angle (H × V)
    • 160° × 150°
    • Brightness Uniformity
    • 97%
    • Color Uniformity
    • ±0.003 Cx, Cy
    • Contrast Ratio
    • 5,000:1
    • Processing Depth (bit)
    • 14

ELECTRICAL SPECIFICATIONS

    • Power Consumption (W/Cabinet, Max.)
    • 413
    • Power Consumption (W/Cabinet, Avg.)
    • 166
    • Power Consumption (W/m², Max.)
    • 510
    • Heat Dissipation (BTU/h/Cabinet, Max.)
    • 1,410
    • Heat Dissipation (BTU/h/Cabinet, Avg.)
    • 566
    • Heat Dissipation (BTU/h/m², Max.)
    • 1,740
    • Power Supply (Vac)
    • 100 to 240
    • Frame Rate (Hz)
    • 50 / 60
    • Refresh Rate (Hz)
    • 3,840

OPERATION SPECIFICATIONS

    • Operating Temperature
    • -4°F to +104°F -20°C to +40°C
    • Operating Humidity
    • 10-80%RH
    • IP Rating Front / Rear
    • IP50 / IP50

REGULATORY & CERTIFICATIONS

    • Regulatory
    • CE, FCC, cTUVus, CB, KC, CCC, Class C
    • Certification (Fire Protection)
    • EN 13501-1

ENVIRONMENT

    • Environment
    • RoHS, REACH

CONTROLLER

    • Controller
    • CVBA

90 DEGREE CORNER CUT

    • 90 Degree corner cut
    • No

WARRANTY

    • Warranty
    • 3 Year Limited

Max Output Range

    • Loading Capacity
    • 3,840 × 2,160 @ 60 Hz
    • Output Resolution
    • 8.2944 Million Pixels

INPUT

    • Input
    • HDMI 2.0, HDCP 2.2, DP 1.2 / HDCP 1.3, OPS

OUTPUT

    • Output
    • Ethernet (To LED Screen (16-channel))

Control

    • LAN
    • Yes
    • RS-232C
    • Yes (LOOP)
    • USB
    • Yes (Service Only)
    • Remote Control
    • Yes

Sensor

    • Temperature (Embeded Sonsor)
    • Yes

Video Processing

    • Video Processing
    • Brightness Adjustment, Chroma Adjustment, Improved Grayscale at Low Brightness, Scaling, HDR10 Pro

Application

    • Application
    • SuperSign CMS, webOS API, LG ConnectedCare1 , Configuration SW (LED Assistant)

MECHANICAL

    • Size (W × H × D)
    • 17.4 x 12.1 x 2.5 in. 443 × 307.5 x 63 mm
    • Weight (kg)
    • 10.8 lbs. / 4.9 kg
