PANEL
-
- Panel Size
- 47" class (46.96" measured diagonally)
- Panel Technology
- Edge lit LED
-
- Native Resolution
- 1920 x 1080 (FHD)
- Frame Rate
- 120Hz
-
- Dynamic CR
- 2,000,000:1
- Response Time
- TR: 8ms/Tf:10ms
-
- Viewing Angle(HxV)
- 178° x 178°
- Static (Panel) Contrast Ratio
- 1,400
BROADCASTING SYSTEM
-
- Analog
- Yes (NTSC)
- Digital
- Yes (ATSC / Clear QAM/VSB)
AUDIO
-
- Smart Sound Mode
- Yes
- Audio Output
- 12W + 12W
-
- apt-X codec
- Yes
- Clear Voice II
- Yes
-
- Sound Mode
- Yes (6 Modes: Standard, News, Music, Cinema, Sport, Game)
- Speaker System
- 2.1 ch
-
- Optical Sound Sync
- Yes
- Wireless Sound Sync
- Yes
-
- Sound Expansion
- Yes
- Sound Optimizer
- 3 modes (Off, Wall-Mount Type, Stand Type)
-
- Subwoofer
- Yes
INTERFACE (Side)
-
- HDMI In
- 2 Side
- USB (2.0)
- 1 Side
INTERFACE (Rear)
-
- RF In
- 1 Rear
- AV In
- 1 Rear
-
- Digital Audio Out (Coaxial / Optical)
- 1 (Optical)
- HDMI/HDCP Input
- 1 Rear
-
- USB 2.0
- 1 Rear
- PC Audio Input
- 1 Rear (Sharing with Component In)
-
- RS-232C (D-Sub 9pin)
- 1 Rear (Phone Jack)
- LAN Port
- 2 Rear
-
- RJ45(RJP interface)
- 1 Rear
- TV link Configuration (phone jack type)
- 1 Rear
-
- External Speaker Out
- 1 Rear (3.5mm phone jack)
- PTC Configuration (phone jack type)
- 1 Rear
-
- MPI Jack (RJ-12)
- 1 Rear
- Component in (Y,Pb,Pr)+Audio(L/R)
- 1 Rear
CABINET
-
- Bezel Width (off Bezel) (mm)
- 1.0mm/1.0mm/24.7mm
- Bezel Width (on Bezel) (mm)
- 8.8mm/8.8mm/26.5mm
-
- Weight (Without Stand)
- 28.2 Ibs
- Carton
- 45.1” x 2.78” x 6.2”
-
- Weight (Carton)
- 38.4 Ibs
- Weight (With Stand)
- 29.1 Ibs
-
- VESA™ Standard Mount Interface
- 400mm x 400mm
- Color
- Dark Titan / Stand : Black
-
- Dimensions with Stand (W×H×D)
- 41.8” x 26.7” x 9.7”
- Dimensions without Stand (W×H×D)
- 41.8” x 24.5” x 2.2”
-
- Flame Retardant
- Yes (Back Cover only)
SPECIAL FEATURES
-
- Remote Diagnostic
- Yes
- Auto Configuration
- Yes (EzManager)
-
- HDMI-CEC
- Yes
- HTNG-CEC
- Yes
-
- Welcome Screen (Splash Image)
- Yes
- Remote App Compatibility
- Yes
-
- Pro:Centric
- Yes
- Multicast/Unicast ready
- Yes
-
- IP Streaming
- Yes (RTSC, HLS, SNMP, UDP/MultiCast, USB Port/Video Streaming support (Smartshare) (※IGMPv3 SSM Support)
- APP. (P:C Smart)
- Yes (Commercial CP/Apps)
-
- Smart Energy Saving (Auto Power Off)
- Yes
- Motion eye care (intelligent sensor)
- Yes
-
- Hybrid Streaming (IP & RF) RF)*MultiCast/HTTP Data Carousel
- Yes
- RF(1/2Tuner)
- Yes (2 Tuner)
-
- Pro:Centric Application
- Yes (PCA 3.0)
- MHL
- Yes
-
- Web Browser
- Yes
- HCAP (GEM/FLASH/HTML)
- Yes
-
- DLNA(Movie/Photo/Music)
- Yes (Smart Share)
- Pro:Idiom
- Yes
-
- SI Compatible (TVLink Protocol)
- Yes (MPI protocol)
- b-LAN
- Yes
-
- WiDi (PC to TV)
- Yes
- WiFi
- Yes (built-in)
-
- Multi IR Code
- Yes
- IR Out
- Yes (MPI Jack)
-
- Auto Off / Auto Sleep
- Yes
- RJP Compatibility
- LG,Teleadapt (RJ45, HDMI CEC), G-Link(HDMI-CEC)
-
- RJP Interface
- Yes (RJ45, HDMI)
- External Speaker Out
- Yes (Variable/Fixed/Line Out, 3.5mm, Stereo, Single ended Type(GRD,L+,R+), 1W with 8Ω)
-
- Hotel Mode / PDM / Installer Menu
- Yes (Installer Menu)
- USB
- Yes (USB 2.0)
-
- WiFi Direct
- Yes
- USB Cloning
- Yes
-
- Moving Picture Playback (SD/HD/Plus HD)
- Divx HD
- Picture
- JPEG
-
- Video Mute
- Yes
- Miracast (Mobile to TV)
- Yes
-
- 3D
- Yes
- webOS
- Yes
-
- One Channel Map/Logical Channel Map
- Yes (LCM)
VIDEO
-
- Dynamic Color Enhancer
- Yes
- Triple XD Engine
- Yes
-
- Aspect Ratio
- Yes (5 Modes: 16:9, Just scan, Set by program, 4:3, Zoom)
POWER
-
- Stand-by
- 0.5W↓
- Watts (typical)
- 47.4W
-
- Power Source
- 110 ~ 240V, 50/60Hz
WARRANTY
-
- WARRANTY
- 2-Year Limited Warranty (Parts/Labor)
REMOTE JACK PANEL COMPATIBILITY (RJP)
-
- REMOTE JACK PANEL COMPATIBILITY (RJP)
- G-Link, teleadapt
REQUIRED LISTINGS
-
- Safety
- cUL, UL, FCC, NOM
- RoHS
- Yes
-
- Energy Star 6.0
- Yes
UPC
-
- 47LY970H
- 7 19192 91588 6
