65" 55"
Inquiry to Buy
Add to Wishlist
EXTENDEDCARE PLANS

KEY FEATURES

  • Brightness(Typ.): 400 cd/m² (APL 25%)
  • Bezel: 0.9 mm (Even, Off bezel)
  • Depth: 6.0 mm (Head)
  • Interface: HDMI/ USB 2.0(2)/ DP/ Audio Out/ RS232C/ RJ45/ IR
Artistic Space Beyond Display, LG Wallpaper OLED Signage

PANEL

    • Screen Size
    • 65"
    • Native Resolution
    • 3,840 x 2,160 (UHD)
    • Panel Technology
    • OLED
    • Response Time
    • 1 ms (G to G), 8 ms (MPRT)
    • Brightness
    • 400/150 nits (APL 25%/100%) * Average Picture Level
    • Aspect Ratio
    • 16 : 9
    • Viewing Angle (H x V)
    • 178 x 178
    • Surface Treatment
    • Hard Coating (2H), Anti-reflection Treatment of the Front Polarizer (Reflectance Typ. 1.2%)
    • Orientation
    • Portrait & Landscape
    • Lifetime (Typ.)
    • 30,000 hrs
    • Operation Hours
    • 12 Hrs / 7 Days (Moving Video Only)

CONNECTIVITY

    • Input
    • HDMI, DP, USB 2.0 (2)
    • Output
    • DP, Audio
    • External Control
    • RS232C In/out, RJ45 In/out, External IR Receiver

STANDARD CERTIFICATION

    • Safety
    • IEC 60950-1 / EN 60950-1 / UL 60950-1
    • EMC
    • FCC Class "A" / CE / KC
    • ErP / Energy Star
    • Yes / No

PHYSICAL SPECIFICATIONS

    • Bezel Color
    • Black
    • Packed Weight
    • 51.6 lbs / 23.4 kg
    • Bezel Width
    • (Off bezel) 0.9 mm (Even) (On bezel) 8.1 mm (T), 10.7 mm (B), 8.3 mm (L/R)
    • Dimensions (Carton) (W x H x D)
    • 62.6” x 38.0” x 8.1” / 1,590 x 965 x 205 mm
    • Dimensions (W x H x D)
    • (Head) 56.9” x 32.4” x 0.2” / 1,445.1 x 822.6 x 6.0 mm (Signage Box) 29.7” x 9.4” x 1.4” / 754 x 239 x 35.5 mm
    • Weight
    • 29.8 lbs / 13.5 kg (Set)

ENVIRONMENTAL CONDITIONS

    • Operating Temperature Range
    • 32°F ~ 104°F / 0°C ~ 40°C
    • Operation Humidity Range
    • 10% to 80%

POWER

    • Power Supply
    • 100–240V~, 50/60Hz
    • Power Type
    • Built-in Power
    • Power Consumption (Typ/Max)
    • 440 W (8 color bar) / 478 W (8 color bar)

SPECIAL FEATURES

    • Yes
    • Internal Memory (64GB), Temperature Sensor, webOS 3.0+, Embedded CMS (USB Auto Playback, Local Contents Scheduling, Group Manager), Fail Over, Content Sync (RS232C, Local Network), OSD Rotation, Tile Mode Setting, Setting Data Cloning, Firmware Update by Network, SNMP, ISM Mode, Control Manager, Crestron Connected(1) DPM, Energy Saving, PM Mode, Wake on LAN, Power on Delay, HDMI-CEC2), SI Server Setting, webRTC

MEDIA PLAYER COMPATIBILITY

    • External Media Player Attachable
    • Yes
    • OPS Type Compatible
    • No

ACCESSORIES

    • Basic
    • Remote Controller (2ea Batteries Included), Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (1,150mm x 4ea for Connection Between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable)

SOFTWARE COMPATIBILITY

    • Content Management Software
    • SuperSign CMS
    • Control and Monitoring Software
    • SuperSign Control+/Control

Brochures

CAD

Case Study

Specification Sheet

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
