KEY FEATURES

  • Enhanced Performance Warranty
  • High Power Output
  • Roof Aesthetics
High Efficiency LG NeON® R Module Cells: 6 x 10 Module efficiency 20.6% Connector Type: MC4

CERTIFICATIONS & WARRANTY

    • Certifications
    • IEC 61215, IEC 61730-1/-2, UL 1703, IEC (Salt mist corrosion test), IEC62716 (Ammonia corrosion test), ISO 9001
    • Module Fire Performance
    • Type 1
    • Fire Resistance Class (CANADA)
    • Class C (ULC / ORD C1703)
    • Product Warranty
    • 25 years
    • Output Warranty of Pmax
    • Linear warranty**
    • **
    • 1) First 5 years : 95%, 2) After 5th year : 0.4% annual degradation, 3) 25 years : 88.4%

ELECTRICAL PROPERTIES(NOCT*)

    • Maximum Power(Pmax)
    • 267
    • MPP Voltage (Vmpp)
    • 36.2
    • MPP Current (Impp)
    • 7.39
    • Open Circuit Voltage (Voc)
    • 40.2
    • Short Circuit Current (Isc)
    • 8.68
    • *
    • NOCT (Nominal Operating Cell Temperature): Irradiance 800 W/m2, ambient temperature 20 °C, wind speed 1 m/s

Electrical Properties (STC*)

    • MPP Voltage (Vmpp)
    • 36.3
    • MPP Current (Impp)
    • 9.79
    • Open Circuit Voltage (Voc)
    • 42.7
    • Short Circuit Current (Isc)
    • 10.78
    • Module Efficiency (%)
    • 20.6
    • Operating Temperature (°C)
    • -40 ~ +90
    • Maximum System Voltage (V)
    • 1000
    • Maximum Series Fuse Rating (A)
    • 20
    • Power Tolerance (%)
    • 0 ~ +3
    • *
    • STC (Standard Test Condition): Irradiance 1,000 W/m², Ambient Temperature 25 °C, AM 1.5 / The nameplate power output is measured and determined by LG Electronics at its sole and absolute discretion. / The Typical change in module efficiency at 200W/m² in relation to 1000W/m2 is -2.0%.
    • Maximum Power (Pmax)
    • 355

MECHANICAL PROPERTIES

    • Cells
    • 6 x 10
    • Cell vendor
    • LG
    • Cell Type
    • Monocrystalline / N-type
    • Cell Dimensions
    • 161.7 x 161.7 mm / 6 inches
    • # of Busbar
    • 30 (Multi Ribbon Busbar)
    • Dimensions (L x W x H)
    • 1700 x 1016 x 40 mm / 66.93 x 40.0 x 1.57 inch
    • Front Load
    • 6000 Pa / 125 psf
    • Rear Load
    • 5400 Pa / 113 psf
    • Weight
    • 18.5 kg
    • Connector Type
    • MC4
    • Junction Box
    • IP68 with 3 Bypass Diodes
    • Length of Cables
    • 1000 mm x 2 ea
    • Frame
    • Anodized aluminium
    • Glass
    • Tempered Glass with AR Coating

Temperature Characteristics

    • NOCT
    • 44 ± 3 °C
    • Pmpp
    • -0.30 %/°C
    • Voc
    • -0.24 %/°C
    • Isc
    • 0.04 %/°C
